Ford Transit Custom

    Ford Transit Custom

    $56,590 - $62,990 excl. on-roads

    About the Ford Transit Custom

    Last updated Jun 07, 2024

    The next generation of Ford’s Toyota HiAce rival has been priced, ahead of customer deliveries beginning in the second quarter of 2024.

    The 2024 Ford Transit Custom range will open at $55,990 before on-road costs, an increase of $5800 over the outgoing base model.

    The long-wheelbase version is $1000 more. Only one roof height is available for now.

    Ford has previously confirmed the electric E-Transit Custom is also coming in 2024, but for now it has detailed only the diesel-powered range. While prices have increased significantly, there’s more standard tech than before.

    Fuel Efficiency7.2 - 7.6 L / 100km
    ANCAP RatingNot tested
    Warranty5 years
    Ford
    8.3

    News

    All the latest Ford Transit Custom news

    Ford Transit Custom Range Guide

    Which variant of the Ford Transit Custom range is best for you?

    The Transit Custom Trend SWB and LWB come standard with:

    • 13-inch touchscreen infotainment system
    • Wireless Apple CarPlay and Android Auto
    • Satellite navigation
    • 5G embedded modem
    • Wireless phone charger
    • FordPass app connectivity
    • Drive mode selection: Normal, Eco, Slippery and Tow/Haul
    • Load Area Protection Kit
    • Side and rear door protection
    • Moulded load floor liner
    • LED load bay lighting

    The only option is a set of dual side load doors with no windows, for $1000.

    Compare

    See Ford Transit Custom comparisons against similarly sized vehicles
    GET EXPERT ADVICE FOR FREE! CALL US ON 1300 587 992

    Interior

    Photos and Images of the Ford Transit Custom Interior

    The old 8.0-inch screen is replaced with a significantly larger 13-inch unit, and Android Auto and Apple CarPlay can now be connected wirelessly.

    A wireless phone charger is standard, as is – for the first time in a Ford in Australia – a 5G embedded modem.

    The transmission shifter has been moved to the column and there’s now an electric parking brake, allowing the driver to enter easily from either side and go into the back without incident.

    Ford also says it has increased space up front by moving the front wheels and strut towers further forward, while the Transit Custom has a shorter front overhang and is lighter than its predecessor.

    Ford Transit Custom Colours

    What colours are available for the Ford Transit Custom?

    Frozen White is standard, with Agate Black, Magnetic and Moondust Silver a $700 option.

    You can also opt for one of 58 special-order colours for an extra $1400

    How it Drives

    Our expert take on Ford Transit Custom drivability?

    The 2024 Ford Transit Custom is powered by a 2.0-litre turbo-diesel four-cylinder engine producing 125kW of power and 390Nm of torque, mated with an eight-speed automatic transmission.

    The new-generation model also boasts independent rear suspension for greater comfort, while braked towing capacity has been bumped 600kg to 2500kg.

    The load floor is lower, and the Transit Custom will slide under the 2m barrier found in many parking lots. It’s also easier to climb into the load compartment thanks to a new access step, and it’s easier to see back there with the old halogen load bay lights replaced with ‘ultra-bright’ LEDs.

    There’s still a wide range of safety features, bolstered by a safe exit warning feature. There’s also a new roof-mounted airbag for the front passenger, which allows the passenger to make use of dashboard storage large enough for a laptop.

    Ford Transit Custom Safety Rating

    ANCAP Safety Rating Australia

    Standard safety equipment includes:

    • Autonomous emergency braking with intersection assist
    • Reverse AEB
    • Adaptive cruise control
    • Blind-spot assist
    • Rear cross-traffic alert
    • Safe exit warning
    • Reversing camera with 180-degree view

    Ford Transit Custom Warranty

    What is the warranty period and kilometre limit for the Ford Transit Custom?

    Ford Transit Custom Boot Space

    How much luggage or cargo capacity and boot space is there in the Ford Transit Custom?

    Total cargo space is 5.8m3 in the SWB and 6.8m3 in the LWB.

    Ford Transit Custom Fuel Economy

    How much fuel does the Ford Transit Custom use and what are its emissions?

    Ford claims combined cycle fuel economy of 8.0L/100km in the 2024 Transit Custom.

    Depending on the variant, view the 2024 FORD TRANSIT CUSTOM fuel usage below.

    All Highway, City, and Combined figures below are litres per 100km

    VariantSeriesStyleFuel TypeHighwayCityCombinedE10?
    TREND (SWB)AV MY24.50VANDIESEL--7.2-
    TREND (LWB)AV MY24.50VANDIESEL--7.6-
    SPORT (SWB)AV MY24.50VANDIESEL--7.2-
    SPORT DCiV (LWB)AV MY24.50DUAL CAB VANDIESEL--7.6-

    Ford Transit Custom Dimensions

    The dimensions of the Ford Transit Custom

    Braked towing capacity is 2500kg on both models.

    Payload is 1269kg in the SWB and 1223kg in the LWB.

    Maximum load length is 3050mm in the SWB model using the load-through feature under the passenger seat, or 3450mm in the LWB.

    Total cargo space is 5.8m3 in the SWB and 6.8m3 in the LWB.

    Depending on the variant, the 2024 FORD TRANSIT CUSTOM measures as below.

    VariantSeriesStyleLength (mm)Width (mm)Height (mm)Wheelbase (mm)
    TREND (SWB)AV MY24.50VAN4972203019642933
    TREND (LWB)AV MY24.50VAN5339203219753300
    SPORT (SWB)AV MY24.50VAN4972203019642933
    SPORT DCiV (LWB)AV MY24.50DUAL CAB VAN5339203219753300

    The 2024 FORD TRANSIT CUSTOM has a braked towing capacity of 2500kg and an unbraked towing capacity of 750kg.

    Ford Transit Custom Market Fit

    Where does it fit in the competitor segment?

    The Ford Transit Custom is categorised as a VANS/CC 2.5-3.5t and has a price range of $56,590 to $62,990.

    Frequently Asked Questions

    Enquiring through CarExpert is one of the easiest ways to order a new 2024 Ford Transit Custom. We connect you with an accredited dealer/s and equip you with information on current deals, what others have paid, plus, our independent reviews and ratings. You can also call our friendly Concierge team whenever you need support - they remain on hand throughout the process to ensure you get the service (and value!) we demand of our partnered dealers.


    When you buy a new 2024 Ford Transit Custom through CarExpert, speed, confidence and great value come standard.

    The Ford Transit Custom range kicks off from $56,590 (plus on-road costs) for the "Transit Custom TREND (SWB)" variant and finishes at $62,990 (plus on-road costs) for the "Transit Custom SPORT DCiV (LWB)" variant.

    The Ford Transit Custom is built in Turkey and is then shipped to Australia.

    The Ford Transit Custom has a braked towing capacity of 2500kg and an unbraked towing capacity of 750kg.

    Ford suggested that owners service their Ford Transit Custom every 12 months or 30,000km, whichever comes first.

    The Ford Transit Custom has not been tested by ANCAP yet.

    The Ford Transit Custom uses Diesel.

    The Ford Transit Custom comes in 2 or 4 door variants.

    In our latest review the Ford Transit Custom scored 8.2 out of 10. Read the full Ford Transit Custom review here.

    The Ford Transit Custom had a 5 year, unlimited km warranty.
