2013 Toyota HiLux WORKMATE (4x4) Specifications
About the 2013 Toyota HiLux WORKMATE (4x4)
The 2013 Toyota HiLux WORKMATE (4x4) is a four-wheel drive dual cab pickup that was released to the Australian market on 01/09/2011 classified as a KUN26R MY12. The HiLux is regarded as a pick up or cab chassis 4x4 built in Thailand with prices from a dealer as a used car starting at A$22,600.
The HiLux is a four-wheel drive 4 door with 5 seats, powered by a 3.0L DIESEL TURBO 4 engine that has 126 kW of power (at 3600 rpm) and 343 Nm of torque (at 1400 rpm) via a Five-speed Manual. TOYOTA claims the HiLux WORKMATE (4x4) uses 8.3L/100km of Diesel in the combined city and highway cycle while putting out 219g of CO2. It has a 75L fuel tank, meaning it should be able to travel 904km per full tank.
The HiLux measures 1850mm (72.8 inches) in height, 5135mm (202.2 inches) in length, 1760mm (69.3 inches) in width with a 3085mm (121.5 inches) wheelbase that brings about a total of 1845kg (6802.4 lbs) of unladen weight. The HiLux WORKMATE (4x4) comes standard with 205/70 R15 front tyres and 205/70 R15 rear tyres. It requires a service every 6 months or 10,000 km, whichever comes first.
The 2013 Toyota HiLux WORKMATE (4x4) has a 212mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.583.
The HiLux has received a 4 star rating from ANCAP. The VIN number can be found on the Rear Driver Side Chassis and the compliance plate is located on the Lower Pass Side Centre Pillar. An example VIN number would be similar to MR0FZ29G700123456.
Reviews
There are no current reviews of this variant. Click here to see reviews for other variants of the Toyota HiLux| Toyota HiLux WORKMATE (4x4) Details | |
|---|---|
| Price | - |
| Used Price From Dealer | A$22,600 |
| Trade-In Value | A$17,900 |
| Series | KUN26R MY12 |
| Body Style | dual cab pickup |
| Release date | 01/09/2011 |
| Discontinued date | 31/01/2014 |
| Drive type | 4x4 |
| VIN plate location | Rear Driver Side Chassis |
| Compliance plate location | Lower Pass Side Centre Pillar |
| VIN Example | MR0FZ29G700123456 |
| Country of origin | Thailand |
| Segment | Pick Up or Cab Chassis 4X4 |
| Safety ANCAP rating | 4 stars |
| Number of doors | 4 |
| Seating capacity | 5 |
| Toyota HiLux WORKMATE (4x4) Engine Specifications | |
| Type | DIESEL TURBO F/INJ |
| Size | 2982cc, 3.0L |
| Power @ RPM | 126kW @ 3600rpm (169.0 hp) |
| Torque @ RPM | 343Nm @ 1400rpm (252.9 lb-ft) |
| Cylinders | turbocharged four-cylinder |
| Number of Valves | 16 |
| Valves | DUAL OVERHEAD CAM |
| Euro Rating | - |
| Compression ratio | 17.9 |
| Power/weight ratio | 68.3kw/tonne |
| Bore/stroke | 96mm × 103mm (3.8in × 4.1in) |
| Toyota HiLux WORKMATE (4x4) Drivetrain and Wheels | |
| Transmission | Five-speed Manual |
| Drive type | four-wheel drive |
| Steering type | RACK & PINION - POWER ASSISTED |
| Turning circle | 12.4m (40.7 ft) |
| Brake (front) type | DISC - VENTILATED |
| Brake (rear) type | DRUM |
| Front tyre & wheel size | 205/70 R15 - 6x15 |
| Rear tyre & wheel size | 205/70 R15 - 6x15 |
| Front suspension type | Double wishbone, Coil Spring, Hydraulic double acting shock absorber |
| Rear suspension type | Leaf spring, Hydraulic double acting shock absorber |
| Toyota HiLux WORKMATE (4x4) Fuel Specifications | |
| Fuel type | DIESEL |
| Fuel tank capacity | 75L |
| Fuel consumption (combined average) | 8.3L / 100km |
| Fuel consumption city (average) | - |
| Fuel consumption highway (average) | - |
| Vehicle range | 903.6km (561.5 miles) |
| Emission standard | - |
| E10 compatible | - |
| CO2 emissions (combined) | 219g / 100km |
| CO2 emissions (city) | - |
| CO2 emissions (highway) | - |
| Toyota HiLux WORKMATE (4x4) Dimensions | |
| Length | 5135mm (202.2 inches) |
| Width | 1760mm (69.3 inches) |
| Height | 1850mm (72.8 inches) |
| Wheelbase | 3085mm (121.5 inches) |
| Front track | 1510mm (59.4 inches) |
| Rear track | 1510mm (59.4 inches) |
| Ground clearance | 212mm (8.3 inches) |
| Unladen weight | 1845kg (4068.2 lbs) |
| Gross Vehicle Mass | 2780kg (6129.9 lbs) |
| Gross Combination Mass | - |
| Toyota HiLux WORKMATE (4x4) Towing Capacity | |
| Braked towing capacity | 2500kg (5512.5 lbs) |
| Unbraked towing capacity | 750kg (1653.8 lbs) |
| Toyota HiLux WORKMATE (4x4) Warranty | |
| Warranty length | 36 months |
| Warranty distance | 100,000km |
| Toyota HiLux WORKMATE (4x4) Servicing | |
| Service interval (km) | 10,000 km |
| Service interval (months) | 6 months |
| Toyota HiLux WORKMATE (4x4) Options | |
| Standard Features |
|
| Optional Features |
|
