2021 LDV G10 BARN DOOR Specifications

LDV Logo
MRLP A$33,221
3 stars

About the 2021 LDV G10 BARN DOOR

The 2021 LDV G10 BARN DOOR is a rear-wheel drive four-door van that was released to the Australian market on 01/10/2020 classified as a SV7C MY21. The G10 is regarded as a VAN 2.5-3.5t built in China with prices starting at A$33,221 before on-road costs.

The G10 is a rear-wheel drive 4 door with 2 seats, powered by a 1.9L DIESEL TURBO 4 engine that has 106 kW of power (at 4000 rpm) and 350 Nm of torque (at 1800 rpm) via a Six-speed Manual. LDV claims the G10 BARN DOOR uses 8.3L/100km of Diesel in the combined city and highway cycle while putting out 0g of CO2. It has a 75L fuel tank, meaning it should be able to travel 904km per full tank.

The G10 measures 1928mm (75.9 inches) in height, 5168mm (203.5 inches) in length, 1980mm (78.0 inches) in width with a 3198mm (125.9 inches) wheelbase that brings about a total of 1970kg (4343.1 lbs) of unladen weight. The G10 BARN DOOR comes standard with 215/70 R16 LT front tyres and 215/70 R16 LT rear tyres. It requires a service every 12 months or 10,000 km, whichever comes first.

The 2021 LDV G10 BARN DOOR has a 134mm ground clearance with a 1500kg braked and 750kg unbraked towing capacity.

The G10 has received a 3 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Front Floor. An example VIN number would be similar to LSKG4GL13GA123456.


There are no current reviews of this variant. Click here to see reviews for other variants of the LDV G10
SeriesSV7C MY21
Body Stylefour-door van
Release date01/10/2020
Discontinued date-
Drive typeRWD
VIN plate locationDriver Side Front Floor
Compliance plate locationPass Side Front Floor
VIN ExampleLSKG4GL13GA123456
Country of originChina
SegmentVANS/CC 2.5-3.5t
Safety ANCAP rating3 stars
Number of doors4
Seating capacity2
LDV G10 BARN DOOR Engine Specifications
Size1850cc, 1.9L
Power @ RPM 106kW @ 4000rpm (142.1 hp)
Torque @ RPM350Nm @ 1800rpm (258.1 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
Euro Rating-
Compression ratio15.8
Power/weight ratio53.8kw/tonne
Bore/stroke80mm × 92mm (3.1in × 3.6in)
LDV G10 BARN DOOR Drivetrain and Wheels
TransmissionSix-speed Manual
Drive typerear-wheel drive
Turning circle11.8m (38.7 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size215/70 R16 LT - 6.5Jx16
Rear tyre & wheel size215/70 R16 LT - 6.5Jx16
Front suspension typeMacPherson strut
Rear suspension type5 links, Coil Spring
LDV G10 BARN DOOR Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity75L
Fuel consumption (combined average)8.3L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range903.6km (561.5 miles)
Emission standard-
E10 compatible-
CO2 emissions (combined)-
CO2 emissions (city)-
CO2 emissions (highway)-
LDV G10 BARN DOOR Dimensions
Length5168mm (203.5 inches)
Width1980mm (78.0 inches)
Height1928mm (75.9 inches)
Wheelbase3198mm (125.9 inches)
Front track1680mm (66.1 inches)
Rear track1660mm (65.4 inches)
Ground clearance134mm (5.3 inches)
Unladen weight1970kg (4343.1 lbs)
Gross Vehicle Mass3000kg (6613.9 lbs)
Gross Combination Mass5000kg (11023.1 lbs)
LDV G10 BARN DOOR Towing Capacity
Braked towing capacity1500kg (3306.9 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
LDV G10 BARN DOOR Warranty
Warranty length36 months
Warranty distance100,000km
LDV G10 BARN DOOR Servicing
Service interval (km)10,000 km
Service interval (months)12 months
Standard Features
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Air Conditioning
  • Apple Car Play
  • Audio Media Player
  • Adjustable Steering Wheel - Tilt Only
  • 16 Inch Alloy Wheels
  • Barn Doors
  • Black Interior
  • Bluetooth Connectivity
  • Central Locking
  • Emergency Brake Assist
  • Electronic Brake Force Distribution
  • Electronic Stability Control
  • Fog Lights - Rear
  • Hydraulic Power Assisted Steering
  • Engine Immobiliser
  • Leather Upholstery
  • Multi-media System with 10 inch Touch Screen
  • Parking Distance Control Rear
  • Parking Distance Control Front
  • Power Mirrors With Indicators
  • Power Windows Front
  • Remote Keyless Entry
  • Roof Mounted Drop-down Screen
  • Roll Movement Intervention
  • Reversing Camera
  • Surround Camera System
  • Sliding Doors Dual
  • Sliding Doors Dual - Remote
  • Smartphone Pack
  • Sunroof - 3 with One Opening
  • Spare Wheel - Full Size Alloy Wheel
  • Tyre Pressure Monitoring System
Optional Features-
