2016 BMW 1 Series 18i URBAN LINE

2016 BMW 1 Series 18i URBAN LINE Specifications

BMW Logo
5.4L/100km
5 stars

About the 2016 BMW 1 Series 18i URBAN LINE

The 2016 BMW 1 Series 18i URBAN LINE is a rear-wheel drive five-door hatchback that was released to the Australian market on 01/11/2015 classified as a F20 LCI. The 1 Series is regarded as a small car built in Germany with prices from a dealer as a used car starting at A$26,500.

The 1 Series is a rear-wheel drive 5 door with 5 seats, powered by a 1.5L TURBO 3 engine that has 100 kW of power (at 4500 rpm) and 220 Nm of torque (at 1250 rpm) via a Six-speed Manual. BMW claims the 1 Series 18i URBAN LINE uses 5.4L/100km of Premium Unleaded Petrol in the combined city and highway cycle while putting out 126g of CO2. It has a 52L fuel tank, meaning it should be able to travel 963km per full tank.

The 1 Series measures 1421mm (55.9 inches) in height, 4324mm (170.2 inches) in length, 1765mm (69.5 inches) in width with a 2690mm (105.9 inches) wheelbase that brings about a total of 1310kg (2888.1 lbs) of unladen weight. The 1 Series 18i URBAN LINE comes standard with 205/55 R16 front tyres and 205/55 R16 rear tyres. It requires a service every 24 months or 25,000 km, whichever comes first.

The 2016 BMW 1 Series 18i URBAN LINE has a 140mm ground clearance with a 1200kg braked and 650kg unbraked towing capacity.

The 1 Series has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Inner Guard and the compliance plate is located on the Pass Side Lower B-Pillar. An example VIN number would be similar to WBA1R520%0P700001.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the BMW 1 Series
BMW 1 Series 18i URBAN LINE Details
Price-
Used Price From DealerA$26,500
Trade-In ValueA$21,500
SeriesF20 LCI
Body Stylefive-door hatchback
Release date01/11/2015
Discontinued date31/10/2016
Drive typeRWD
VIN plate locationDriver Side Inner Guard
Compliance plate locationPass Side Lower B-Pillar
VIN ExampleWBA1R520%0P700001
Country of originGermany
SegmentSmall Car
Safety ANCAP rating5 stars
Number of doors5
Seating capacity5
BMW 1 Series 18i URBAN LINE Engine Specifications
TypeTURBO MPFI
Size1499cc, 1.5L
Power @ RPM 100kW @ 4500rpm (134.1 hp)
Torque @ RPM220Nm @ 1250rpm (162.2 lb-ft)
Cylindersturbocharged three-cylinder
Number of Valves12
ValvesVARIABLE DOUBLE OVERHEAD CAM
Euro RatingEuro 6
Compression ratio11
Power/weight ratio76.3kw/tonne
Bore/stroke82mm × 94.6mm (3.2in × 3.7in)
BMW 1 Series 18i URBAN LINE Drivetrain and Wheels
TransmissionSix-speed Manual
Drive typerear-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle10.9m (35.8 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size205/55 R16 - 7x16
Rear tyre & wheel size205/55 R16 - 7x16
Front suspension typeMacPherson strut, Coil Spring, Gas damper, Anti roll bar
Rear suspension typeMacPherson strut, Coil Spring, Gas damper, Anti roll bar
BMW 1 Series 18i URBAN LINE Fuel Specifications
Fuel typePREMIUM UNLEADED PETROL
Fuel tank capacity52L
Fuel consumption (combined average)5.4L / 100km
Fuel consumption city (average)6.7L / 100km
Fuel consumption highway (average)4.7L / 100km
Vehicle range963.0km (598.4 miles)
Emission standardEuro 6
E10 compatible-
CO2 emissions (combined)126g / 100km
CO2 emissions (city)156g / 100km
CO2 emissions (highway)109g / 100km
BMW 1 Series 18i URBAN LINE Dimensions
Length4324mm (170.2 inches)
Width1765mm (69.5 inches)
Height1421mm (55.9 inches)
Wheelbase2690mm (105.9 inches)
Front track1521mm (59.9 inches)
Rear track1556mm (61.3 inches)
Ground clearance140mm (5.5 inches)
Unladen weight1310kg (2888.1 lbs)
Gross Vehicle Mass1840kg (4056.5 lbs)
Gross Combination Mass-
BMW 1 Series 18i URBAN LINE Towing Capacity
Braked towing capacity1200kg (2645.5 lbs)
Unbraked towing capacity650kg (1433.0 lbs)
BMW 1 Series 18i URBAN LINE Warranty
Warranty length36 months
Warranty distanceUnlimited km
BMW 1 Series 18i URBAN LINE Servicing
Service interval (km)25,000 km
Service interval (months)24 months
BMW 1 Series 18i URBAN LINE Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Automatic Air Con / Climate Control
  • Adjustable Front Seats - Manual
  • Ambient Interior Lighting
  • Automatic Stop/Start
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Ambient Temperature Display
  • Anti-theft Wheel Bolts
  • AUX/USB Input Socket
  • 16 Inch Alloy Wheels
  • Brake Assist
  • Brake Energy Regeneration
  • Bottle Holders - Front Seats
  • Brake-pad Wear Indicator
  • Cornering Brake Control
  • Cruise Control
  • Centre Console Box With Sliding Armrest
  • Chrome Exhaust Tip(s)
  • Chrome Grille Surround
  • Cup Holders - Front Seats
  • Chrome Highlight - Interior
  • Cargo Tie Down Hooks/Rings
  • Central Locking Remote Control
  • Dust and Pollen Filter
  • Door Pockets - Front Seat
  • Dynamic Stability Control
  • Electronic Brake Force Distribution
  • Emergency Brake Lights - Flashing
  • Electronic Differential Lock
  • Exterior Mirrors - Heated
  • First-Aid Kit
  • Front Footwell Lights
  • Floor Mats - Front & Rear
  • Headrests - Adjustable on All Seats
  • Head Airbags
  • Halogen Headlights
  • High Mounted Rear Stop Light
  • Engine Immobiliser
  • Keyless Entry and Drive
  • Leather Steering Wheel
  • Leather Upholstery
  • Multi Function Steering Wheel
  • MP3 Compatible Audio/CD Player
  • Mobile Phone Connectivity
  • Power Mirrors With Indicators
  • Power Steering
  • Power Windows
  • Remote Boot/Hatch Release
  • Radio CD with 6 Speakers
  • Remote Fuel Lid Release
  • Runflat Safety Tyres
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear Wiper/Washer
  • Satellite Navigation
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Side Front AirBags
  • Split Fold Rear Seat
  • Scuff Plates - On Doors Sill
  • Start/Stop Button
  • Trip Computer
  • Traction Control System
  • Welcome Lights
Optional Features
  • Auto Climate Control with Dual Temp Zones - A$770
  • Active Steering - A$670
  • Adaptive Damping Control - A$1,690
  • Alarm System/Remote Anti Theft - A$650
  • 17 Inch Alloy Wheels - A$1,230
  • Comfort Pack - A$2,100
  • Digital Audio Broadcast Radio - A$385
  • Driver Assist Pack - A$1,080
  • Innovation Pack - A$2,950
  • LED Headlights - A$1,050
  • Metallic Paint - A$1,140
  • M Sport Package II - A$3,000
  • Parking Distance Control Rear - A$300
  • Protective Glazing - A$510
  • Power Sunroof - A$2,000
  • Sport Seats - A$1,000
  • Sound System with 7 Speakers - A$540
  • Premium Sound System - A$1,190
  • Sports Suspension - A$600
  • Tyre Pressure Monitoring System - A$420
  • Vision Pack - (PSR, XH & SSP) - A$2,850
