2021 Volvo XC90 RECHARGE PHEV Specifications

Volvo Logo
MRLP A$116,990
Not tested

About the 2021 Volvo XC90 RECHARGE PHEV

The 2021 Volvo XC90 RECHARGE PHEV is an all-wheel drive four-door wagon that was released to the Australian market on 01/03/2021 classified as a 256 MY22. The XC90 is regarded as a large SUV built in Sweden with prices starting at A$116,990 before on-road costs.

The XC90 is an all-wheel drive 4 door with 7 seats, powered by a 2.0L S/C & T/C 4CYL engine that has 235 kW of power (at 5700 rpm) and 420 Nm of torque (at 2100 rpm) via an Eight-speed Automatic. VOLVO claims the XC90 RECHARGE PHEV uses 2.3L/100km of Premium Unleaded-Electric Hybrid in the combined city and highway cycle while putting out 53g of CO2. It has a 71L fuel tank, meaning it should be able to travel 3087km per full tank.

The XC90 measures 1776mm (69.9 inches) in height, 4953mm (195.0 inches) in length, 1923mm (75.7 inches) in width with a 2984mm (117.5 inches) wheelbase that brings about a total of 2315kg (5103.7 lbs) of unladen weight. The XC90 RECHARGE PHEV comes standard with 275/45 R22 front tyres and 275/45 R22 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2021 Volvo XC90 RECHARGE PHEV has a 223mm ground clearance with a 2400kg braked and 750kg unbraked towing capacity.

The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Centre A-Pillar. An example VIN number would be similar to YV1LF06ACH1000000.


There are no current reviews of this variant. Click here to see reviews for other variants of the Volvo XC90
Volvo XC90 RECHARGE PHEV Details
Series256 MY22
Body Stylefour-door wagon
Release date01/03/2021
Discontinued date-
Drive typeAWD
VIN plate locationDriver Side Front Floor
Compliance plate locationPass Side Centre A-Pillar
VIN ExampleYV1LF06ACH1000000
Country of originSweden
SegmentLarge SUV
Safety ANCAP ratingNot tested
Number of doors4
Seating capacity7
Volvo XC90 RECHARGE PHEV Engine Specifications
TypeS/C & T/C GDi
Size1969cc, 2.0L
Power @ RPM 235kW @ 5700rpm (315.1 hp)
Torque @ RPM420Nm @ 2100rpm (309.7 lb-ft)
Cylinderssupercharged and turbocharged four-cylinder
Number of Valves16
Euro Rating-
Compression ratio10.3
Power/weight ratio101.5kw/tonne
Bore/stroke82mm × 93.2mm (3.2in × 3.7in)
Volvo XC90 RECHARGE PHEV Drivetrain and Wheels
TransmissionEight-speed Automatic
Drive typeall-wheel drive
Turning circle11.8m (38.7 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC - VENTILATED
Front tyre & wheel size275/45 R22 - 9x22
Rear tyre & wheel size275/45 R22 - 9x22
Front suspension typeDouble wishbone, Hydraulic shock absorber, Coil Spring, Stabiliser bar
Rear suspension typeIntegral Axle, Leaf spring, Hydraulic shock absorber, Stabiliser bar
Volvo XC90 RECHARGE PHEV Fuel Specifications
Fuel tank capacity71L
Fuel consumption (combined average)2.3L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range3087.0km (1918.2 miles)
Emission standard-
E10 compatible-
CO2 emissions (combined)53g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Volvo XC90 RECHARGE PHEV Dimensions
Length4953mm (195.0 inches)
Width1923mm (75.7 inches)
Height1776mm (69.9 inches)
Wheelbase2984mm (117.5 inches)
Front track1665mm (65.6 inches)
Rear track1667mm (65.6 inches)
Ground clearance223mm (8.8 inches)
Unladen weight2315kg (5103.7 lbs)
Gross Vehicle Mass-
Gross Combination Mass-
Volvo XC90 RECHARGE PHEV Towing Capacity
Braked towing capacity2400kg (5291.1 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Volvo XC90 RECHARGE PHEV Warranty
Warranty length60 months
Warranty distanceUnlimited km
Volvo XC90 RECHARGE PHEV Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Volvo XC90 RECHARGE PHEV Options
Standard Features
  • 12 Volt Power Outlet - Load Area
  • Second Row Seats- Manual Release
  • 2 Stage Unlocking OFF
  • 340mm Rear Brakes
  • 366mm Front Brakes
  • 3rd Row Climate Unit
  • Climate Control - 4 Zone incl Cooled Glovebox
  • Seven Seat Interior
  • Automatically Activated Hazard Lights
  • Dual Front Airbags Package
  • Airbag Knee Driver
  • Anti-lock Braking
  • Automatic Air Con / Climate Control
  • Adaptive Cruise Control
  • Alarm without Blocked Lock Mode
  • Alarm Logic Base
  • Alarm with Interior Movement Sensor
  • Active Noise Control EOE
  • Air Suspension - 4 Corner
  • Air Suspension with Four-C Active Chassis
  • Adjustable Speed Limiter
  • 22 Inch Alloy Wheels
  • Bag Hooks
  • Brake Assist
  • Black Alloy Wheels
  • Body Coloured Sills & Bumpers
  • Body Coloured Exterior Door Handles
  • Black Exterior Accents
  • Black Exterior Mirrors
  • Battery H8 AGM 95ah 850 CCA
  • Black Headliner
  • Blind Spot Information System
  • Bluetooth Connectivity
  • Bumper - Painted R-design
  • Black Window Surrounds - Exterior
  • Curtain Airbags
  • Cargo Divider
  • Cargo Cover - Semi Automatic
  • Cloth Headlining
  • Central Locking Interior Switch - Front Doors
  • Central Locking Interior Switch - Rear Doors
  • Central Locking Remote Control
  • CleanZone
  • Cavity Noise Damping Tyres
  • Connector (EU Type)
  • Child Proof Rear Door Locks
  • Child Seat Centre Rear Seat
  • Child Seat - ISOFIX Anchorage System
  • Cushion Extension
  • Digital Audio Broadcast Radio
  • Driver Mode Selection
  • Digital Owners Manual
  • Electronic Brake Force Distribution
  • Emergency Brake Lights - Flashing
  • Electric Motor
  • Exterior Mirrors - Auto Dimming
  • Electric Power Steering
  • Electric Rear Axle Drive
  • Extra USB Socket/s
  • Forward Collision Mitigation
  • Front Cross Traffic Alert
  • Gloss Finish Exterior Window Surrounds
  • Headrests - Adjustable Rear Seats
  • Hill Descent Control
  • Heated Front Seats
  • High Level Interior Lighting
  • Humidity Sensor
  • Hill Start Assist
  • High Mounted Rear Stop Light
  • Hands-Free Smart Tailgate
  • Hidden Tailpipes
  • Head Up Display
  • High Voltage Battery
  • High Voltage Coolant Heater
  • Hybrid Drive System
  • Interior Carpeted
  • Instrument Cluster Display - 12.3 Inch
  • Intelligent Driver Information System
  • Illuminated Door Sill Panels
  • Engine Immobiliser
  • Leather Accented Steering Wheel
  • Leather Accented Upholstery
  • Lights on Exterior Door Handles
  • LED Headlights Bending, Cornering if Fog Lights
  • Leather Gear Knob - R-Design
  • Lithium-ion Battery
  • Lane Keeping Assist
  • Load Protection Net
  • Multifilter
  • Multi Function Steering Wheel
  • Manual Sunblinds - Rear Side Windows
  • Metal Treadplates with Branding
  • No Automotive Service (iCUP)
  • Number Plate Adapter
  • Park Assist Pilot
  • Park Assist Front & Rear
  • Painted Wheel Arches
  • Power Child Locks
  • Personal Profile - Power Steering
  • Power front seats with memory
  • Scuff Plate - Loadspace
  • Puddle Lamps
  • Power Lumbar Support Driver 4-way
  • Power Lumbar Support Passenger 4-way
  • Pilot Assist
  • Professional Navigation System
  • Power Opening Fuel Filler Door
  • Preventilation/Prolonged Heating - Engine Shut Off
  • Powered Panoramic Sunroof
  • Power Tailgate
  • Private Locking
  • Rain Sensor
  • Rear Centre Armrest with Cup Holders
  • Rear Collision Mitigation
  • Rear Cross Traffic Alert
  • Rear Collision Warning
  • R-Design Grille
  • R-Design Pedals
  • Roof Rails Black Finish
  • Roof Rails Gloss Finish
  • Retractable Rear View Mirrors
  • Rear Spoiler - Body Colour
  • Rear Spoiler Hatch Mounted
  • Road Sign Information
  • Rear View Mirror Auto Dimming
  • Side Airbags
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Rear Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Surround Camera System
  • Special Identifying Badging
  • Smartphone Interface
  • Panoramic Sunroof
  • Storage Recess - Under Floor in Rear Cargo Area
  • Premium Sound System - Bowers and Wilkins
  • Sports Steering Wheel
  • Storage Tray RH Side Cargo Area
  • Subwoofer
  • Sunvisors with Vanity Mirrors & Illumination
  • Steering Wheel Inlays
  • Tempered Glass Side & Rear Windows
  • Ticket Holder A-pillar
  • Tailored Instrument Panel
  • Transport Protection Cover - Opening for Tailgate
  • Tyre Pressure Monitoring System
  • Third Row Armrest/ Cupholder & Storage LH/RH Side
  • Tyre Repair Kit
  • Third Row Seats
  • Tilt Sensor
  • Towing Eyes
  • Tinted Windows - Rear
  • USB Input Socket
  • VEA Gen 2
  • Ventilated Front Disc Brakes
  • Ventilated Rear Disc Brakes
  • Voice Recognition System
  • Wet Arms Windscreen Washers
  • Wheel Finish - Diamond Cut
  • Without UREA
  • Wireless Phone Charge
  • Wheel Plastic Protection Cap
  • Whiplash protection System - Front Seats
  • Warning Triangle
Optional Features
  • Advanced Air Cleaner - A$500
  • Alloy Wheels Special 22 Inch - A$2,500
  • Climate Pack - A$700
  • Heated Rear Seats - A$430
  • Heated Steering Wheel - A$320
  • Headlight Washer System - A$150
  • Metallic Paint - A$2,000
  • Massage Seats Front - A$1,050
  • Nubuck Headlining - A$1,500
  • Pearl Effect Paint - A$2,000
  • Power Folding Headrest - Rear - A$350
  • Perf Nappa Leather Accented Upholstery - Two-tone - A$3,100
