2014 Volvo S60 T5 R-DESIGN

2014 Volvo S60 T5 R-DESIGN Specifications

Volvo Logo
6.4L/100km
5 stars

About the 2014 Volvo S60 T5 R-DESIGN

The 2014 Volvo S60 T5 R-DESIGN is a front-wheel drive four-door sedan that was released to the Australian market on 01/06/2014 classified as a F MY14. The S60 is regarded as a medium car built in Sweden with prices from a dealer as a used car starting at A$23,200.

The S60 is a front-wheel drive 4 door with 5 seats, powered by a 2.0L TURBO 4 engine that has 180 kW of power (at 5500 rpm) and 350 Nm of torque (at 1500 rpm) via an Eight-speed Automatic. VOLVO claims the S60 T5 R-DESIGN uses 6.4L/100km of Premium Unleaded Petrol in the combined city and highway cycle while putting out 149g of CO2. It has a 67L fuel tank, meaning it should be able to travel 1047km per full tank.

The S60 measures 1484mm (58.4 inches) in height, 4628mm (182.2 inches) in length, 1865mm (73.4 inches) in width with a 2776mm (109.3 inches) wheelbase that brings about a total of 1664kg (3668.5 lbs) of unladen weight. The S60 T5 R-DESIGN comes standard with 235/40 R18 front tyres and 235/40 R18 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2014 Volvo S60 T5 R-DESIGN has a 136mm ground clearance with a 1800kg braked and 750kg unbraked towing capacity.

The S60 has received a 5 star rating from ANCAP. The VIN number can be found on the Centre Top Scuttle and the compliance plate is located on the Lower Left Firewall. An example VIN number would be similar to YV1FS4732B1000001.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Volvo S60
Volvo S60 T5 R-DESIGN Details
Price-
Used Price From DealerA$23,200
Trade-In ValueA$18,300
SeriesF MY14
Body Stylefour-door sedan
Release date01/06/2014
Discontinued date31/10/2014
Drive typeFWD
VIN plate locationCentre Top Scuttle
Compliance plate locationLower Left Firewall
VIN ExampleYV1FS4732B1000001
Country of originSweden
SegmentMedium Car
Safety ANCAP rating5 stars
Number of doors4
Seating capacity5
Volvo S60 T5 R-DESIGN Engine Specifications
TypeTURBO MPFI
Size1968cc, 2.0L
Power @ RPM 180kW @ 5500rpm (241.4 hp)
Torque @ RPM350Nm @ 1500rpm (258.1 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesVARIABLE DOUBLE OVERHEAD CAM
Euro Rating-
Compression ratio-
Power/weight ratio108.2kw/tonne
Bore/stroke82mm × 93.2mm (3.2in × 3.7in)
Volvo S60 T5 R-DESIGN Drivetrain and Wheels
TransmissionEight-speed Automatic
Drive typefront-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle11.9m (39.0 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size235/40 R18 - 8x18
Rear tyre & wheel size235/40 R18 - 8x18
Front suspension typeMacPherson strut, Coil Spring, Gas damper, Anti roll bar
Rear suspension typeMulti-link system, Coil Spring, Gas damper, Anti roll bar
Volvo S60 T5 R-DESIGN Fuel Specifications
Fuel typePREMIUM UNLEADED PETROL
Fuel tank capacity67L
Fuel consumption (combined average)6.4L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range1046.9km (650.5 miles)
Emission standard-
E10 compatible-
CO2 emissions (combined)149g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Volvo S60 T5 R-DESIGN Dimensions
Length4628mm (182.2 inches)
Width1865mm (73.4 inches)
Height1484mm (58.4 inches)
Wheelbase2776mm (109.3 inches)
Front track1588mm (62.5 inches)
Rear track1585mm (62.4 inches)
Ground clearance136mm (5.4 inches)
Unladen weight1664kg (3668.5 lbs)
Gross Vehicle Mass2070kg (4563.6 lbs)
Gross Combination Mass-
Volvo S60 T5 R-DESIGN Towing Capacity
Braked towing capacity1800kg (3968.3 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Volvo S60 T5 R-DESIGN Warranty
Warranty length36 months
Warranty distanceUnlimited km
Volvo S60 T5 R-DESIGN Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Volvo S60 T5 R-DESIGN Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Automatic Air Con / Climate Control
  • Adaptive Headlights
  • Autonomous Emergency Braking
  • Automatic Stop/Start
  • Ambient Temperature Display
  • AUX/USB Input Socket
  • 18 Inch Alloy Wheels
  • Brake Assist
  • Brake Energy Regeneration
  • Cruise Control
  • Chrome Exhaust Tip(s)
  • Cup Holders - Front and Rear
  • Centre Console Box - Multi-purpose
  • Central Locking Remote Control
  • Child Proof Rear Door Locks
  • Collapsible Steering Column
  • Digital Clock
  • Dust and Pollen Filter
  • Door Pockets - Front Seat
  • Daytime Running Lights - LED
  • Electronic Brake Force Distribution
  • Emergency Brake Lights - Flashing
  • Exterior Mirrors - Auto Dimming
  • Exterior Mirrors - Heated
  • Exterior Mirrors with Puddle Light
  • Electric Parking Brake
  • Electronic Stability Program
  • Floor Mats - Front & Rear
  • Headrests - Adjustable on All Seats
  • Head Airbags
  • Headlights - Coming/Leaving Home Function
  • High Mounted Rear Stop Light
  • Headlight Washer System
  • Illuminated - Entry/Exit with Delayed Fade
  • Illuminated Glove Box Compartment
  • Engine Immobiliser
  • Lockable Glove Box Compartment
  • Leather Gear Knob
  • Leather Steering Wheel
  • Leather Upholstery
  • Multi Function Control Screen
  • Multi Function Steering Wheel
  • MP3 Compatible Audio/CD Player
  • Mobile Phone Connectivity
  • Map/Reading Lights - Front
  • Parking Distance Control Rear
  • Power front seats
  • Power Mirrors With Indicators & Folding
  • Power Steering
  • Power Windows
  • Rear Centre Armrest
  • Remote Boot/Hatch Release
  • Radio CD with 10 Speakers
  • Rear Spoiler
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear View Mirror Auto Dimming
  • Rear Window Demister
  • Side Airbags
  • Satellite Navigation
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Speed Sensing Auto Door Lock
  • Split Fold Rear Seat
  • Side Impact Protection
  • Scuff Plates - On Doors Sill
  • Seatback Pockets - Front Seats
  • Sport Seats
  • Sports Suspension
  • Sunvisors with Vanity Mirrors & Illumination
  • Spare Wheel - Space Saver/Temporary
  • Trip Computer
  • Traction Control System
  • Trailer Stability Control
Optional Features
  • Alarm System/Remote Anti Theft - A$850
  • Cruise Control Intelligent/Active - A$4,175
  • Driver Alert System - A$2,075
  • Driver Alert System Plus - A$6,250
  • Driver Support Pack - A$4,990
  • Heated Front Seats - A$325
  • Lane Change Warning - A$1,275
  • Lane Departure Warning - A$2,075
  • Metallic Paint - A$1,550
  • Power Sunroof - A$2,650
  • Premium Sound System - A$1,425
  • Xenon Headlights - A$2,550
