Peugeot Boxer Pro (2023) price & specs
Pro
Overview
The 2023 Peugeot Boxer Pro is a front-wheel drive, 4-door Panel Van that was released to the Australian market on 1st February 2024. The Peugeot Boxer is regarded as a Van Over 3.5t built in Italy with prices starting at $52,990 before on-road costs.
This Peugeot Boxer is powered by a 2.2L 4-cylinder engine that has 121 kW of power (at 3750 rpm) and 370 Nm of torque (at 1750 rpm) via a Six-speed Manual transmission. Peugeot claims the Boxer Pro uses 7.5L/100km of Diesel in the combined city and highway cycle while putting out 196g of CO2. It has a 90L fuel tank, meaning it should be able to travel 1200km per full tank
The Peugeot Boxer measures 2522mm (99.3 inches) in height, 5998mm (236.1 inches) in length, 2050mm (80.7 inches) in width with a 4035mm (158.9 inches) wheelbase that brings about a total of 2035kg (4486.4 lbs) of unladen weight. The Boxer Pro comes standard with 215/70 R15 front tyres and 215/70 R15 rear tyres. It requires a service every 12 months or 20,000 km, whichever comes first. It has a 60 month, 200,000 km warranty.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Boxer compare?
Quickly see how the 2023 Peugeot Boxer Pro stacks up against its competition.
 Select any benchmark to see more details.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
in mirror: 2,690 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,998 mm |
| Overall Width | 2,050 mm |
| Overall Width (Inc Mirror) | 2,690 mm |
| Overall Height | 2,522 mm |
| Wheelbase | 4,035 mm |
| Turning Circle | 14,200 mm |
| Load Capacity | 1,475 mm |
Looking for complete Peugeot Boxer size & space specs?
Our Peugeot Boxer Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Peugeot Boxer Features & Specs
Compressor
Compressor: Turbo
Compressor Number Of: 1
Electrical System
Electrical System Voltage: 12
Emission Control Level
Emission Control Level Standard Met: EU6
Emission Control Level Co2 Level Combined: 196
Engine
Engine Liters: 2.2
Engine Configuration: In-Line
Engine Cc: 2179
Engine Number Of Cylinders: 4
Fuel
Fuel Type: Diesel
Fuel Generic Primary Fuel Type: Diesel
Fuel Minimum Fuel Type: Diesel
Fuel Tanks
Fuel Tanks Main Type: Total
Fuel Tanks Main Capacity L: 90
Fuel Tanks Main Capacity Gal: 23.8
Fuel Tanks Main Capacity Uk Gallons: 19.8
Computer
Computer Average Fuel Consumption: yes
Display Screen
Display Screen Dashboard Centre1 Location: Dashboard Centre 1
Display Screen Dashboard Centre1 Screen Size Inch: 5.00
Display Screen Dashboard Centre1 Touch Screen: yes
Display Screen Dashboard Centre1 Orientation: Fixed
Fuel Consumption
Fuel Consumption Adr8102 Standard: Adr 81/02
Fuel Consumption Adr8102 Combined L100km: 7.5
Fuel Consumption Adr8102 Combined Mpg: 31
Fuel Consumption Adr8102 Combined Miles Per Uk Gallon: 38
Fuel Consumption Adr8102 Combined Km Ll: 13.3
Fuel Consumption Adr8102 Calculated Vehicle Range Km: 1200
Fuel Consumption Adr8102 Calculated Vehicle Range Miles: 746
Fuel Consumption Adr8102 Urban Mpg: 27
Fuel Consumption Adr8102 Urban L100km: 8.7
Fuel Consumption Adr8102 Country Highway Mpg: 35
Fuel Consumption Adr8102 Country Highway L100km: 6.7
Fuel Consumption Adr8102 Urban Miles Per Uk Gallon: 33
Fuel Consumption Adr8102 Country Highway Miles Per Uk Gallon: 42
Fuel Consumption Adr8102 Urban Km Ll: 11.5
Fuel Consumption Adr8102 Country Highway Km Ll: 14.9
Fuel Economy
Fuel Economy Adr8102 L100km: 7.5
Power
Power Maximum Power Kw: 121
Power Maximum Power Hp Ps: 165
Power Maximum Torque Nm: 370
Power Rpm For Maximum Torque Low: 1750
Power Measurement Standard: EEC
Power Rpm For Maximum Power Low: 3750
Power Primary Or Secondary Fuel Power Figure: Primary
Drive
Drive Driven Wheels: Front
Transmission
Transmission Type: Manual
Transmission Number Of Speeds: 6
Transmission Description: Manual
Transmission Shift Lever Location: Dash
Transmission Number Of Simulated Gears: 0
Disc Brakes
Disc Brakes Number Of: 4
Disc Brakes Number Of Ventilated Discs: 2
Steering Wheel
Steering Wheel Type: Plastic
Steering Wheel Telescopic Adjustment: yes
Suspension
Suspension Rear Location: Rear
Suspension Rear Spring Type: Leaf
Suspension Front Location: Front
Suspension Front Spring Type: Coil
Suspension Rear Wheel Dependence: Rigid
Suspension Front Type: Strut
Suspension Rear Type: Beam
Suspension Front Stabilizer Bar: yes
Suspension Front Wheel Dependence: Independent
Tires
Wheels Tire Rear Location: Rear
Wheels Tire Front Location: Front
Wheels Tire Rear Width: 215
Wheels Tire Front Width: 215
Wheels Tire Rear Profile: 70
Wheels Tire Front Profile: 70
Wheels Tire Front Speed Rating: R
Wheels Tire Rear Speed Rating: R
Wheels Tire Front Type: Conventional/Summer
Wheels Tire Rear Type: Conventional/Summer
Wheels Tire Front Load Index: 109
Wheels Tire Rear Load Index: 109
Wheels
Wheels Rear Axle1 Axle Location: 1
Wheels Rear Location: Rear
Wheels Front Location: Front
Wheels Rear Rim Diameter Inch: 15
Wheels Front Rim Diameter Inch: 15
Wheels Front Rim Type: Steel
Wheels Rear Rim Type: Steel
Wheels Front Rim Width Inch: 6.0
Wheels Rear Rim Width Inch: 6.0
Body Style
Body Type: Panel Van
Local Body Type: Panel Van
Platform Code: U3
Wheelbase Type: Long
Cab Type: Single Cab
Roof Type: Semi-High
Bumpers
Front Location: Front
Rear Location: Rear
Front Color: Black
Rear Color: Black
Cargo Area Dimensions
Cargo Area Standard Measurement: Manufacturer'S Own
Cargo Area Length In: 145.9
Cargo Area Length Mm: 3707
Cargo Area Width Mm: 1870
Cargo Area Width In: 73.6
Cargo Area Height In: 76.1
Cargo Area Height Mm: 1870
Cargo Area Width Between Wheelhouses Mm: 1420
Cargo Area Width Between Wheelhouses In: 55.9
Cargo Area Loading Floor Height In: 23.7
Cargo Area Loading Floor Height Mm: 602
Cargo Area Cargo Volume Cu Ft: 459.1
Cargo Area Cargo Volume L: 13000
External Dimensions
External Dimensions Overall Height In: 99.3
External Dimensions Overall Height Mm: 2522
External Dimensions Wheelbase Mm: 4035
External Dimensions Wheelbase In: 158.9
External Dimensions Overall Width In: 80.7
External Dimensions Overall Width Mm: 2050
External Dimensions Overall Length In: 236.1
External Dimensions Overall Length Mm: 5998
External Dimensions Rear Track Mm: 1790
External Dimensions Rear Track In: 70.5
External Dimensions Front Track Mm: 1810
External Dimensions Front Track In: 71.3
External Dimensions Curb To Curb Turning Circle Mm: 14200
External Dimensions Kerb To Kerb Turning Circle Ft: 46.6
External Dimensions Wall To Wall Turning Circle Ft: 47.6
External Dimensions Wall To Wall Turning Circle Mm: 14500
External Dimensions Rear Overhang In: 40.0
External Dimensions Rear Overhang Mm: 1015
External Dimensions Front Overhang Mm: 948
External Dimensions Front Overhang In: 37.3
External Dimensions Overall Width Inc Mirror In: 105.9
External Dimensions Overall Width Inc Mirror Mm: 2690
External Dimensions Overall Width Folded Mirror In: 98.7
External Dimensions Overall Width Folded Mirror Mm: 2508
Cargo Doors
Cargo Doors Rear Location: Rear
Cargo Doors Rear Operation: Double Hinged
Cargo Doors Rear Opening Angle: 270
Cargo Doors Rear Height Mm: 1790
Cargo Doors Rear Height In: 70.5
Cargo Doors Rear Width Mm: 1562
Cargo Doors Rear Width In: 61.5
Cargo Doors Passenger Location: Passenger
Cargo Doors Passenger Operation: Sliding
Cargo Doors Passenger Width In: 49.2
Cargo Doors Passenger Width Mm: 1250
Cargo Doors Passenger Height Mm: 1755
Cargo Doors Passenger Height In: 69.1
Doors
Doors Passenger Location: Passenger
Doors Driver Location: Driver
Doors Passenger Type: Front Hinged
Doors Driver Type: Front Hinged
Headlight Control
Headlight Control Height Adjustment: Manual
Headlights
Headlights Bulb Type Low Beam: Halogen
Headlights Lens Type: Complex Surface
Headlights Bulb Type High Beam: Halogen
Led Lights
Led Lights Day Time Running Lights Location: Day Time Running Lights
Paint
External Color: White
Type: Gloss
Door Mirrors Cameras
Door Mirrors Cameras Passenger Location: Passenger
Door Mirrors Cameras Driver Location: Driver
Door Mirrors Cameras Driver Color: Black
Door Mirrors Cameras Passenger Color: Black
Door Mirrors Cameras Driver Type: Electrically Adjustable
Door Mirrors Cameras Passenger Type: Electrically Adjustable
Power Windows
Power Windows Front Location: Front
Windshield Wipers
Windshield Wipers Intermittent Wipe: Variable
Weights
Published Kerb Weight Lbs: 4486
Published Kerb Weight Kg: 2035
Gross Trailer Weight Braked Kg: 2500
Gross Trailer Weight Braked Lbs: 5512
Gross Trailer Weight Unbraked Kg: 750
Gross Trailer Weight Unbraked Lbs: 1653
Gross Vehicle Weight Kg: 3510
Gross Vehicle Weight Lbs: 7738
Tare Weight Kg: 1967
Payload Allowance Lbs: 3435
Payload Allowance Kg: 1558
Gross Train Weight Kg: 6000
Gross Train Weight Lbs: 13228
Trailer Noseweight Kg: 100
Payload Inc Driver Kg: 1558
Payload Inc Driver Lbs: 3435
Audio System
System Radio Type: Am/Fm
System Touch Screen: yes
Connection To Ext Entertainment Devices
Connection External Usb Front: yes
Connection Total Number Of Usb Connections Rear: 0
Connection Total Number Of Usb Connections3rd Row: 0
Remote Audio Controls
Remote Control Type: Steering Wheel Mounted
Speakers
Speaker Number Of Speakers: 2
Bulkhead
Bulkhead Window: yes
Bulkhead Width: Full
Bulkhead Height: Full
Parking Distance System
Parking Distance System Rear Location: Rear
Parking Distance System Rear Type: Sensor & Camera
Power Outlet12v
Power Outlet Front Location12v: Front
Power Outlet Boot Cargo Location12v: Boot/Cargo
Usb Charging Port
Usb Charging Port Front Location: Front
Airbags
Number Of Airbags: 2
Front Airbag
Front Airbag Driver Location: Driver
Front Airbag Passenger Location: Passenger
Front Seat Belts
Front Seat Belts Passenger Seat Position: Passenger
Front Seat Belts Driver Seat Position: Driver
Front Seat Belts Passenger Height Adjustable: yes
Front Seat Belts Driver Height Adjustable: yes
Front Seat Belts Center Seat Position: Center
Head Restraints
Head Restraints Front Seats Location: Front Seats
Front Seat
Front Seat Passenger Location: Passenger
Front Seat Driver Location: Driver
Front Seat Passenger Type: Bench
Front Seat Driver Type: Bucket
Front Seat Driver Height Type: Manual
Front Seat Driver Reach Type: Manual
Front Seat Driver Lumbar Type: Manual
Front Seat Passenger Lumbar Type: Manual
Front Seat Driver Reclining Type: Manual
Front Seat Center Location: Centre
Front Seat Center Type: Bench
Seat Upholstery
Seat Upholstery Main Seat Material: Cloth
Seat Upholstery Additional Seat Material: Cloth
Seating
Seating Capacity: 3
Seating Configuration: 3+0
Below Seat Storage
Below Seat Storage Passenger Location: Passenger
Below Seat Storage Driver Location: Driver
Cup Holders
Cup Holders Front Seats Location: Front Seats
Air Conditioning
Air Conditioning Type: Fully-Auto
Power Locks
Power Locks Operation: Remote
Intermediate Service
Intermediate Service Distance Km: 20000
Intermediate Service Distance Miles: 12427
Intermediate Service Period Months: 12
