Base
Overview
The 2022 Iveco Daily Base is a four-wheel drive, 2-door Cab Chassis that was released to the Australian market on 2nd August 2023 classified as a E6. The Iveco Daily is regarded as a Van Over 3.5t built in Italy and when it was new had prices starting at .
This Iveco Daily is powered by a 3.0L 4-cylinder engine that has 132 kW of power (at 3500 rpm) and 430 Nm of torque (at 1500 rpm) via an Eight-speed Automatic transmission. It has a 90L fuel tank
The Iveco Daily measures 2501mm (98.5 inches) in height, 6818mm (268.4 inches) in length, 2056mm (80.9 inches) in width with a 4175mm (164.4 inches) wheelbase that brings about a total of 3000kg (6613.9 lbs) of unladen weight. The Daily Base comes standard with 265/70 R19.5 front tyres and 265/70 R19.5 rear tyres. It requires a service every 12 months or 40,000 km, whichever comes first. It has a 36 month, 100,000 km warranty.
The 2022 Iveco Daily Base has a 225mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity.
How does the Daily compare?
Quickly see how the 2022 Iveco Daily Base stacks up against its competition.
Select any benchmark to see more details.
Power to Weight
39.23 - 44.47 kW/t
38.22 kW/t
68.24 kW/t
Warranty (Years)
3 years
3 years
5 years
Warranty (Distance)
100,000 km
100,000 km
Unlimited
Years on Sale
2 - 4 years
2 years
4 years
Service Interval
12 months
12 months
24 months
Towing & Off-Road Capability
Gross Vehicle Weight
7,000 kg
3,500 kg
7,000 kg
Gross Comb. Mass
10,500 kg
4,250 kg
10,500 kg
Braked Towing Capacity
3,500 kg
1,700 kg
3,500 kg
Approach Angle
35°
35°
Departure Angle
17 - 33°
17°
33°
Ground Clearance Unladen
225 mm
143 mm
231 mm
Payload Capacity
3,635 - 4,032 kg
911 kg
4,032 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
6,818 mm
2,056 mm
2,501 mm
| Specification | Measurement |
|---|---|
| Overall Length | 6,818 mm |
| Overall Width | 2,056 mm |
| Overall Height | 2,501 mm |
| Wheelbase | 4,175 mm |
| Turning Circle | 16,100 mm |
| Load Capacity | 4,000 mm |
Looking for complete Iveco Daily size & space specs?
Our Iveco Daily Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Iveco Daily Features & Specs
Compressor
Compressor: Turbo
Compressor Number Of: 1
Electrical System
Electrical System Voltage: 12
Emission Control Level
Emission Control Level Standard Met: EU6
Engine
Engine Liters: 3.0
Engine Configuration: In-Line
Engine Cc: 2998
Engine Number Of Cylinders: 4
Engine Bore: 95.8
Engine Stroke: 104.0
Engine Engine Code: F1cfl411f
Fuel
Fuel Type: Diesel
Fuel Generic Primary Fuel Type: Diesel
Fuel Minimum Fuel Type: Diesel
Fuel Tanks
Fuel Tanks Main Type: Total
Fuel Tanks Main Capacity L: 90
Fuel Tanks Main Capacity Gal: 23.8
Fuel Tanks Main Capacity Uk Gallons: 19.8
Computer
Computer Average Fuel Consumption: yes
Display Screen
Display Screen Dashboard Centre1 Location: Dashboard Centre 1
Display Screen Dashboard Centre1 Screen Size Inch: 7.00
Display Screen Dashboard Centre1 Touch Screen: yes
Display Screen Instrument Cluster1 Location: Instrument Cluster 1
Display Screen Instrument Cluster1 Screen Size Inch: 3.50
Display Screen Dashboard Centre1 Orientation: Fixed
Power
Power Maximum Power Kw: 132
Power Maximum Power Hp Ps: 180
Power Maximum Torque Nm: 430
Power Rpm For Maximum Torque Low: 1500
Power Measurement Standard: EEC
Power Rpm For Maximum Power Low: 3500
Power Primary Or Secondary Fuel Power Figure: Primary
Differential Lock
Differential Lock Rear Location: Rear
Differential Lock Center Location: Centre
Differential Lock Front Location: Front
Drive
Drive Driven Wheels: 4x4
Drive Four Wheel Drive Type: Full-Time
Transmission
Transmission Type: Automatic
Transmission Number Of Speeds: 8
Transmission Manual Mode: yes
Transmission Low High Gear Ranges: yes
Transmission Description: Automatic With Manual Mode
Transmission Shift Lever Location: Dash
Transmission Code: Zf 8v470a
Transmission Number Of Simulated Gears: 0
Disc Brakes
Disc Brakes Number Of: 2
Disc Brakes Number Of Ventilated Discs: 2
Power Steering
Power Steering Type: Electric
Steering Wheel
Steering Wheel Type: Leather Covered
Steering Wheel Telescopic Adjustment: yes
Suspension
Suspension Rear Location: Rear
Suspension Rear Spring Type: Leaf
Suspension Front Location: Front
Suspension Front Spring Type: Leaf
Suspension Rear Wheel Dependence: Rigid
Suspension Front Type: Beam
Suspension Rear Type: Beam
Suspension Front Stabilizer Bar: yes
Suspension Front Wheel Dependence: Rigid
Suspension Rear Stabilizer Bar: yes
Tires
Wheels Tire Rear Location: Rear
Wheels Tire Front Location: Front
Wheels Tire Rear Width: 265
Wheels Tire Front Width: 265
Wheels Tire Rear Profile: 70
Wheels Tire Front Profile: 70
Wheels Tire Front Speed Rating: R
Wheels Tire Rear Speed Rating: R
Wheels Tire Front Type: Conventional/Summer
Wheels Tire Rear Type: Conventional/Summer
Wheels
Wheels Rear Axle1 Axle Location: 1
Wheels Rear Location: Rear
Wheels Front Location: Front
Wheels Rear Rim Diameter Inch: 19.5
Wheels Front Rim Diameter Inch: 19.5
Wheels Front Rim Type: Steel
Wheels Rear Rim Type: Steel
Wheels Front Rim Width Inch: 6.5
Wheels Rear Rim Width Inch: 6.5
Body Style
Body Type: Cab Chassis
Local Body Type: Cab Chassis
Platform Code: X70
Wheelbase Type: Short
Cab Type: Single Cab
Roof Type: Standard
Underbody Protection
Underbody Protection Engine Location: Engine
External Dimensions
External Dimensions Overall Height In: 98.5
External Dimensions Overall Height Mm: 2501
External Dimensions Wheelbase Mm: 4175
External Dimensions Wheelbase In: 164.4
External Dimensions Overall Width In: 80.9
External Dimensions Overall Width Mm: 2056
External Dimensions Overall Length In: 268.4
External Dimensions Overall Length Mm: 6818
External Dimensions Rear Track Mm: 1713
External Dimensions Rear Track In: 67.4
External Dimensions Front Track Mm: 1725
External Dimensions Front Track In: 67.9
External Dimensions Curb To Curb Turning Circle Mm: 16100
External Dimensions Kerb To Kerb Turning Circle Ft: 52.8
External Dimensions Ground Clearance Unladen Mm: 225
External Dimensions Ground Clearance Unladen In: 8.9
External Dimensions Rear Overhang In: 67.5
External Dimensions Rear Overhang Mm: 1715
External Dimensions Front Overhang Mm: 928
External Dimensions Front Overhang In: 36.5
Ramp Angles
Ramp Angles Approach Angle: 35.0
Ramp Angles Departure Angle: 17.0
Bumpers
Front Location: Front
Rear Location: Rear
Front Color: Black
Rear Color: Black
Doors
Doors Passenger Location: Passenger
Doors Driver Location: Driver
Doors Passenger Type: Front Hinged
Doors Driver Type: Front Hinged
Headlight Control
Headlight Control Height Adjustment: Manual
Headlights
Headlights Bulb Type Low Beam: Halogen
Headlights Lens Type: Complex Surface
Headlights Bulb Type High Beam: Halogen
Paint
External Color: White
Type: Gloss
Door Mirrors Cameras
Door Mirrors Cameras Passenger Location: Passenger
Door Mirrors Cameras Driver Location: Driver
Door Mirrors Cameras Driver Color: Black
Door Mirrors Cameras Passenger Color: Black
Door Mirrors Cameras Driver Type: Electrically Adjustable
Door Mirrors Cameras Passenger Type: Electrically Adjustable
Power Windows
Power Windows Front Location: Front
Windshield Wipers
Windshield Wipers Intermittent Wipe: Fixed
Weights
Published Kerb Weight Lbs: 6614
Published Kerb Weight Kg: 3000
Gross Trailer Weight Braked Kg: 3500
Gross Trailer Weight Braked Lbs: 7716
Gross Trailer Weight Unbraked Kg: 750
Gross Trailer Weight Unbraked Lbs: 1653
Gross Vehicle Weight Kg: 7000
Gross Vehicle Weight Lbs: 15432
Tare Weight Kg: 2932
Payload Allowance Lbs: 8819
Payload Allowance Kg: 4000
Front Axle Weight Kg: 2700
Front Axle Weight Lbs: 5953
Rear Axle Weight Kg: 5000
Rear Axle Weight Lbs: 11023
Gross Train Weight Kg: 10500
Gross Train Weight Lbs: 23149
Kerb Weight Includes Driver: yes
Kerb Weight Inc Driver Kg: 3000
Kerb Weight Inc Driver Lbs: 6614
Payload Inc Driver Kg: 4075
Payload Inc Driver Lbs: 8984
Manufacturer Driver Weight Kg: 75
Manufacturer Driver Weight Lbs: 165
Audio System
System Radio Type: Am/Fm
System Digital Radio: yes
System Touch Screen: yes
Connection To Ext Entertainment Devices
Connection External Usb Front: yes
Connection Total Number Of Usb Connections Rear: 0
Connection Total Number Of Usb Connections Front: 1
Connection Total Number Of Usb Connections3rd Row: 0
Remote Audio Controls
Remote Control Type: Steering Wheel Mounted
Speakers
Speaker Number Of Speakers: 4
Mobile Integration
Mobile Integration Apple Carplay: yes
Mobile Integration Android Auto: yes
Power Outlet12v
Power Outlet Front Location12v: Front
Usb Charging Port
Usb Charging Port Front Location: Front
Usb Charging Port Front Number: 1
Front Seat Belts
Front Seat Belts Passenger Seat Position: Passenger
Front Seat Belts Driver Seat Position: Driver
Front Seat Belts Passenger Height Adjustable: yes
Front Seat Belts Driver Height Adjustable: yes
Front Seat Belts Center Seat Position: Center
Head Restraints
Head Restraints Front Seats Location: Front Seats
Front Seat
Front Seat Passenger Location: Passenger
Front Seat Driver Location: Driver
Front Seat Driver Heated: yes
Front Seat Passenger Type: Bench
Front Seat Driver Type: Bucket
Front Seat Driver Height Type: Manual
Front Seat Driver Reach Type: Manual
Front Seat Driver Lumbar Type: Manual
Front Seat Driver Reclining Type: Manual
Front Seat Center Location: Centre
Front Seat Center Type: Bench
Seat Upholstery
Seat Upholstery Main Seat Material: Cloth
Seat Upholstery Additional Seat Material: Cloth
Seating
Seating Capacity: 3
Seating Configuration: 3+0
Cup Holders
Cup Holders Front Seats Location: Front Seats
Air Conditioning
Air Conditioning Type: Fully-Auto
Aircon Climate Control Number Of Zones: 1
Power Locks
Power Locks Operation: Remote
Intermediate Service
Intermediate Service Distance Km: 40000
Intermediate Service Distance Miles: 24855
Intermediate Service Period Months: 12
