Base
1.8L, 5-speed auto, 5-door Station Wagon, Petrol, FWD
Save $$$ with CarExpert*
$49,800â€
Volkswagen Passat Base (2002) price & specs
From
$49,800â€
Save thousands with CarExpert*
Base
Overview
The 2002 Volkswagen Passat Base is a front-wheel drive, 5-door Station Wagon that was released to the Australian market on 4th January 1970. The Volkswagen Passat is regarded as a medium-sized car built in Germany with prices starting at $49,800 before on-road costs.
This Volkswagen Passat is powered by a 1.8L 4-cylinder engine that has 110 kW of power (at 5700 rpm) and 210 Nm of torque (at 1750 rpm) via a Five-speed Automatic transmission. It has a 62L fuel tank
The Volkswagen Passat measures 1498mm (59.0 inches) in height, 4682mm (184.3 inches) in length, 1746mm (68.7 inches) in width with a 2703mm (106.4 inches) wheelbase that brings about a total of 1509kg (3326.8 lbs) of unladen weight. The Passat Base comes standard with 205/60 R15 front tyres and 205/60 R15 rear tyres. It has a 36 month, 100,000 km warranty.
The 2002 Volkswagen Passat Base has a 124mm ground clearance with a 1300kg braked and 650kg unbraked towing capacity.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Passat compare?
Quickly see how the 2002 Volkswagen Passat Base stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
72.9 - 113.04 kW/t
64.34 kW/t
127.09 kW/t
Boot Space
400 - 525 litres
398 litres
690 litres
Price
$45,900 - $97,900
$23,990
$97,900
Warranty (Years)
3 years
3 years
5 years
Warranty (Distance)
60,000 - 100,000 km
60,000 km
Unlimited
Towing & Off-Road Capability
Gross Vehicle Weight
1,870 - 2,300 kg
1,825 kg
2,300 kg
Braked Towing Capacity
1,300 - 2,200 kg
1,000 kg
2,200 kg
Ground Clearance Unladen
124 mm
118 mm
167 mm
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
4,682 mm
1,746 mm
1,498 mm
| Specification | Measurement |
|---|---|
| Overall Length | 4,682 mm |
| Overall Width | 1,746 mm |
| Overall Height | 1,498 mm |
| Wheelbase | 2,703 mm |
| Load Capacity | 361 mm |
Looking for complete Volkswagen Passat size & space specs?
Our Volkswagen Passat Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Volkswagen Passat Features & Specs
Compressor
Compressor: Turbo
Engine
Bore Engine: 81
Engine (cc): 1781
Compression Ratio: 9.5
Engine Configuration: In-Line
Engine (L): 1.8
Number of Cylinders: 4
Number of Valves per Cylinder: 5
Stroke Engine: 86.4
Valve Gear Type: Double Overhead Cam
Fuel
Generic Primary Fuel Type: Petrol
Fuel Type: Premium Unleaded
Fuel System
Injection Carburetion: Multi-Point Injection
Fuel Tanks
Main Capacity Gal: 16.4
Main Capacity (L): 62
Main Fuel Type: Premium Unleaded
Main Type: Total
Computer
Average Fuel Consumption: yes
Average Speed: yes
Instantaneous Fuel Consumption: yes
Range for Remaining Fuel: yes
Fuel Consumption
AS 2877 Country Highway (L/100km): 6
AS 2877 Country Highway (mpg): 39
AS 2877 Standard: As 2877
AS 2877 Urban (L/100km): 9.8
AS 2877 Urban (mpg): 24
Fuel Economy
AS 2877 City (L/100km): 9.8
AS 2877 Highway (L/100km): 6
Performance
Acceleration 0 To 100 km/h: 10.8
Maximum Speed (km/h): 208
Maximum Speed (mph): 129
Power
Maximum Power (hp/PS): 150
Maximum Power (kW): 110
Maximum Torque (Nm): 210
Measurement Standard: EEC
Rpm For Maximum Power Low: 5700
Rpm For Maximum Torque Low: 1750
Drive
Driven Wheels: Front
Electronic Traction Control
Controlled By: ABS
Transmission
Electronic Control Auto Only: yes
Lock Up Auto Only: yes
Manual Mode: yes
Mode Select Auto Only: yes
Number of Speeds: 5
Shift Lever Location: Floor
Type: Automatic
ABS
Location: 4-Wheel
Disc Brakes
Number of Disc Brakes: 4
Number of Ventilated Disc Brakes: 2
Steering Wheel
Height Adjustment: yes
Telescopic Adjustment: yes
Type: Leather Covered
Suspension
Location: Front
Front Spring Type: Coil
Front Stabilizer Bar: yes
Front Type: Multi-Link
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Coil
Rear Stabilizer Bar: yes
Rear Type: Torsion Beam
Rear Wheel Dependence: Semi-Independent
Tires
Location: Front
Front Wheels Tire Profile: 60
Front Wheels Tire Speed Rating: V
Front Wheels Tire Width: 205
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 60
Rear Wheels Tire Speed Rating: V
Rear Wheels Tire Width: 205
Wheels
Location: Front
Front Wheels Rim Diameter (In): 15
Front Wheels Rim Type: Alloy
Front Wheels Rim Width (In): 7
Location: Rear
Rear Rim Diameter (In): 15
Rear Rim Type: Alloy
Rear Wheels Rim Width (In): 7
Body Style
Body Type: Station Wagon
Driver Location: RHD
Local Body Type: Station Wagon
Chrome Bright Trim
Bright Chrome Trim Around Side Windows: yes
Non-Corrosive Body
Non-Corrosive Panel Location: Full
Non-Corrosive Panel Type: Galvanised
Bumpers
Front Bumper Colour: Painted
Location: Front
Rear Bumper Colour: Painted
Location: Rear
Cargo Area Dimensions
Length to Back of Rear Station Wagons (in): 44.3
Length to Back of Rear Station Wagons: 1124
Cargo Capacity
Rear Seat Down (cu ft): 54.6
Rear Seat Down (L): 1545
Rear Seat Up to Lower Window (cu ft): 18.5
Rear Seat Up to Lower Window (L): 525
External Dimensions
Front Track (in): 59.6
Front Track (mm): 1515
Ground Clearance Unladen (in): 4.9
Ground Clearance Unladen (mm): 124
Overall Height (in): 59
Overall Height (mm): 1498
Overall Length (in): 184.3
Overall Length (mm): 4682
Overall Width (in): 68.7
Overall Width (mm): 1746
Rear Track (in): 59.6
Rear Track (mm): 1515
Wall to Wall Turning Circle (ft): 37.7
Wall to Wall Turning Circle (mm): 11500
Wheelbase (in): 106.4
Wheelbase (mm): 2703
Internal Dimensions
Front Headroom (in): 39.8
Front Headroom (mm): 1011
Rear Headroom (in): 39.6
Rear Headroom (mm): 1006
Front Hip Room (in): 57.7
Front Hip Room (mm): 1466
Rear Hip Room (in): 56.7
Rear Hip Room (mm): 1440
Front Leg Room (in): 44.7
Front Leg Room (mm): 1136
Rear Leg Room (in): 35.7
Rear Leg Room (mm): 906
Headlight Control
Internal Height Adjustment: yes
Headlights
Low Beam Bulb Type: Halogen
Lens Type: Ellipsoidal
Paint
Type: Gloss
Sunroof
Front Sunroof Location: Front
Front Sunroof Operation: Electric
Front Sunroof Sliding: yes
Front Sunroof Sunshade: yes
Front Sunroof Tilting: yes
Front Sunroof Type: Glass
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Painted
Heated Driver Door Mirrors/Cameras: yes
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Painted
Heated Passenger Door Mirrors/Cameras: yes
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Number of Front Express Power Windows: 2
Safety Operation for Front Power Windows: yes
Rear Electric Windows: Rear
Safety Operation for Rear Power Windows: yes
Windshield Wipers
Intermittent Wipe Windshield Wipers: Automatic
Weights
Gross Trailer Weight Braked (kg): 1300
Gross Trailer Weight Braked (lb): 2866
Gross Trailer Weight Unbraked (kg): 650
Gross Trailer Weight Unbraked (lb): 1433
Gross Vehicle Weight (kg): 1870
Gross Vehicle Weight (lb): 4123
Published Kerb Weight (kg): 1509
Published Kerb Weight (lb): 3327
Antenna
Type: Roof
Audio Anti-Theft Protection
Type: Code
Audio System
In-Dash CD: yes
Radio Type: Am/Fm
Speakers
Number of Speakers: 8
Cargo Area Cover Rear Parcel Shelf
Type: Flexible
Load Restraint
Type: Hooks
Cigar Lighter
Location: Front Seats
Courtesy Lights
Delayed Fade: yes
Reading Lights
Location: Front
Location: Rear
Remote Trunk Hatch Release
Operation: Remote Control
Vanity Mirror
Driver Mirror Illuminated: yes
Driver Mirror Location: Driver
Passenger Mirror Illuminated: yes
Location: Passenger
Floor Mats
Material: Textile
Luxury Trim
Centre Floor Console: Alloy
Doors: Alloy
Gear Selector: Leather
Instrument Panel: Alloy
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Operation: Reel
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Driver Type: 3-Point
Passenger Height Adjustable: yes
Passenger Operation: Reel
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Passenger Type: 3-Point
Head Restraints
Front Seats Height Adjustable: yes
Front Seats Location: Front Seats
Front Seats Number: 2
Rear Seats Height Adjustable: yes
Rear Seats Location: Rear Seats
Rear Seats Number: 3
Rear Seat Belts
Center Operation: Reel
Center Seat Position: Centre
Center Type: 3-Point
Driver Operation: Reel
Driver Seat Position: Driver
Driver Type: 3-Point
Passenger Operation: Reel
Passenger Seat Position: Passenger
Passenger Type: 3-Point
Side Airbag
Location: Front
Front Seat
Driver Front Seat Height Adjustment: yes
Location: Driver
Driver Front Seat Lumbar Adjustment: yes
Driver Front Seat Type: Sports
Passenger Front Seat Height Adjustment: yes
Location: Passenger
Passenger Front Seat Lumbar Adjustment: yes
Passenger Front Seat Type: Sports
Seat Upholstery
Additional Seat Material: Cloth
Main Seat Material: Cloth
Seating
Capacity: 5
Cup Holders
Location: Front Seats
Front Seats Type: Fixed
Location: Rear Seats
Rear Seats Type: Pop Out
Door Pockets Bins
Location: Driver
Location: Passenger
Seat Back Storage
Location: Front
Air Conditioning
Fully Automated Climate Control: yes
Ventilation System
Digital Display: yes
Micro Filter: yes
Anti-Theft Protection
Interior Monitoring: yes
Peripheral: yes
Remote Operation: yes
Power Locks
Includes Power Windows: yes
Includes Sunroof: yes
Includes Trunk Hatch: yes
Operation: Remote
