2021 Volvo XC60 B6 R-DESIGN MHEV

2021 Volvo XC60 B6 R-DESIGN MHEV Specifications

Volvo Logo
MRLP A$80,990
Not tested

About the 2021 Volvo XC60 B6 R-DESIGN MHEV

The 2021 Volvo XC60 B6 R-DESIGN MHEV is an all-wheel drive four-door wagon that was released to the Australian market on 01/03/2021 classified as a 246 MY22. The XC60 is regarded as a medium SUV built in Sweden with prices starting at A$80,990 before on-road costs.

The XC60 is an all-wheel drive 4 door with 5 seats, powered by a 2.0L TURBO 4 engine that has 220 kW of power (at 5400 rpm) and 420 Nm of torque (at 2100 rpm) via an Eight-speed Automatic. VOLVO claims the XC60 B6 R-DESIGN MHEV uses 8L/100km of Premium Unleaded-Electric Hybrid in the combined city and highway cycle while putting out 182g of CO2. It has a 71L fuel tank, meaning it should be able to travel 888km per full tank.

The XC60 measures 1653mm (65.1 inches) in height, 4708mm (185.4 inches) in length, 1902mm (74.9 inches) in width with a 2865mm (112.8 inches) wheelbase that brings about a total of 1886kg (4157.9 lbs) of unladen weight. The XC60 B6 R-DESIGN MHEV comes standard with 255/40 R21 front tyres and 255/40 R21 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2021 Volvo XC60 B6 R-DESIGN MHEV has a 211mm ground clearance with a 2400kg braked and 750kg unbraked towing capacity.

The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Centre A-Pillar. An example VIN number would be similar to LYVUZ06A1K1123456.


There are no current reviews of this variant. Click here to see reviews for other variants of the Volvo XC60
Volvo XC60 B6 R-DESIGN MHEV Details
Series246 MY22
Body Stylefour-door wagon
Release date01/03/2021
Discontinued date-
Drive typeAWD
VIN plate locationDriver Side Front Floor
Compliance plate locationPass Side Centre A-Pillar
VIN ExampleLYVUZ06A1K1123456
Country of originSweden
SegmentMedium SUV
Safety ANCAP ratingNot tested
Number of doors4
Seating capacity5
Volvo XC60 B6 R-DESIGN MHEV Engine Specifications
Size1969cc, 2.0L
Power @ RPM 220kW @ 5400rpm (295.0 hp)
Torque @ RPM420Nm @ 2100rpm (309.7 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
Euro Rating-
Compression ratio10.5
Power/weight ratio116.6kw/tonne
Bore/stroke82mm × 93.2mm (3.2in × 3.7in)
Volvo XC60 B6 R-DESIGN MHEV Drivetrain and Wheels
TransmissionEight-speed Automatic
Drive typeall-wheel drive
Turning circle11.4m (37.4 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC - VENTILATED
Front tyre & wheel size255/40 R21 - 8.5x21
Rear tyre & wheel size255/40 R21 - 8.5x21
Front suspension typeDouble wishbone, Hydraulic shock absorber, Coil Spring, Stabiliser bar
Rear suspension typeDouble wishbone, Integral Axle, Leaf spring, Hydraulic shock absorber, Stabiliser bar
Volvo XC60 B6 R-DESIGN MHEV Fuel Specifications
Fuel tank capacity71L
Fuel consumption (combined average)8L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range887.5km (551.5 miles)
Emission standard-
E10 compatible-
CO2 emissions (combined)182g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Volvo XC60 B6 R-DESIGN MHEV Dimensions
Length4708mm (185.4 inches)
Width1902mm (74.9 inches)
Height1653mm (65.1 inches)
Wheelbase2865mm (112.8 inches)
Front track1653mm (65.1 inches)
Rear track1657mm (65.2 inches)
Ground clearance211mm (8.3 inches)
Unladen weight1886kg (4157.9 lbs)
Gross Vehicle Mass2500kg (5511.5 lbs)
Gross Combination Mass-
Volvo XC60 B6 R-DESIGN MHEV Towing Capacity
Braked towing capacity2400kg (5291.1 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Volvo XC60 B6 R-DESIGN MHEV Warranty
Warranty length60 months
Warranty distanceUnlimited km
Volvo XC60 B6 R-DESIGN MHEV Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Volvo XC60 B6 R-DESIGN MHEV Options
Standard Features
  • 12 Volt Power Outlet - Load Area
  • Second Row Seats- Manual Release
  • 2 Stage Unlocking OFF
  • 320mm Rear Brakes
  • 345mm Front Brakes
  • Climate Control - 4 Zone incl Cooled Glovebox
  • Five Seat Interior
  • Automatically Activated Hazard Lights
  • Dual Front Airbags Package
  • Airbag Knee Driver
  • Anti-lock Braking
  • Apple Car Play
  • Adaptive Cruise Control
  • Alarm without Blocked Lock Mode
  • Alarm Logic Base
  • Alarm with Interior Movement Sensor
  • Active Noise Control - Engine Order Enhancement
  • Aquablades
  • Adjustable Speed Limiter
  • Android Auto
  • 21 Inch Alloy Wheels
  • Brake Assist
  • Body Coloured Sills & Bumpers
  • Body Coloured Exterior Door Handles
  • Black Exterior Mirrors
  • Battery H7 AGM 80ah 800 CCA
  • Black Headliner
  • Black Wheel Arch Flares
  • Blind Spot Information System
  • Bluetooth Connectivity
  • Bumper - Painted R-design
  • Curtain Airbags
  • Cargo Cover
  • Cargo Liner
  • Cloth Headlining
  • Central Locking Interior Switch - Front Doors
  • Central Locking Interior Switch - Rear Doors
  • CleanZone
  • Child Proof Rear Door Locks
  • Child Seat - ISOFIX Anchorage System
  • Cushion Extension
  • Digital Audio Broadcast Radio
  • Device Mirroring
  • Driver Mode Selection
  • Digital Owners Manual
  • Digital Service
  • Dynamic Chassis
  • Electronic Brake Force Distribution
  • Emergency Brake Lights - Flashing
  • Exterior Mirrors - Auto Dimming
  • Electric Power Steering
  • Forward Collision Mitigation
  • Front Cross Traffic Alert
  • Front Grille - Mesh Insert
  • Fog Lights Front - Cornering if LED Bending
  • Gloss Black Window Trim Strips
  • Headrests - Adjustable Rear Seats
  • Hill Descent Control
  • Heated Front Seats
  • High Level Interior Lighting
  • High Performance Sound System
  • Humidity Sensor
  • Hill Start Assist
  • High Mounted Rear Stop Light
  • Hands-Free Smart Tailgate
  • Head Up Display
  • Interior Carpeted
  • Instrument Cluster Display - 12.3 Inch
  • Intelligent Driver Information System
  • Inlays - Metal Mesh
  • Engine Immobiliser
  • Vehicle Jack
  • Leather Accented Steering Wheel
  • Lights on Exterior Door Handles
  • LED Headlights Bending, Cornering if Fog Lights
  • Leather Gear Knob
  • Lane Keeping Assist
  • Multifilter
  • Multi Function Steering Wheel
  • Metal Treadplates with Branding
  • Nappa Leather Accent/Textile Open Grid Upholstery
  • Number Plate Adapter
  • Park Assist - Front
  • Park Assist - Rear
  • Power Child Locks
  • Puddle Door Lights
  • Personal Profile - Power Steering
  • Power front seats
  • Power front seat Driver/memory
  • Power front seat Passenger/memory
  • Scuff Plate - Loadspace
  • Power Lumbar Support Driver 4-way
  • Power Lumbar Support Passenger 4-way
  • Pilot Assist
  • Power Opening Fuel Filler Door
  • Preventilation/Prolonged Heating - Engine Shut Off
  • Power Tailgate
  • Private Locking
  • Rain Sensor
  • Rear Centre Armrest with Cup Holders
  • Rear Collision Mitigation
  • Rear Cross Traffic Alert
  • Rear Collision Warning
  • R-Design Grille
  • R-Design Pedals
  • Remote Key
  • Roof Rails Black Finish
  • Roof Rails Gloss Finish
  • Retractable Rear View Mirrors
  • Road Sign Information
  • Rear View Mirror Auto Dimming
  • Side Airbags
  • Side Assist
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Rear Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Surround Camera System
  • Special Identifying Badging
  • Sports Steering Wheel
  • Sunvisors with Vanity Mirrors & Illumination
  • Steering Wheel Inlays
  • Spare Wheel - Space Saver/Temporary
  • Telematics
  • Tempered Glass Side & Rear Windows
  • Ticket Holder A-pillar
  • Tailored Instrument Panel
  • Transport Protection Cover - Opening for Tailgate
  • Tyre Pressure Monitoring System
  • Tilt Sensor
  • Towing Eyes
  • USB-C Input Socket/s
  • VEA Gen 3
  • Ventilated Front Disc Brakes
  • Volvo On Call
  • Ventilated Rear Disc Brakes
  • Voice Recognition System
  • With Outer Child Seats
  • Without UREA
  • Wireless Phone Charge
  • Wheel Plastic Protection Cap
  • Whiplash protection System - Front Seats
  • Warning Triangle
Optional Features
  • Advanced Air Cleaner - A$500
  • Air Suspension with Four-C Active Chassis - A$2,600
  • Alloy Wheels Special 22 Inch - A$4,000
  • Climate Pack - A$400
  • Heated Steering Wheel - A$400
  • Headlight Washer System - A$150
  • Lifestyle Pack with Harmon Kardon - A$3,900
  • Lifestyle Pack with Bowers and Wilkins - A$6,200
  • Metallic Paint - A$1,950
  • Massage Seats Front - A$1,050
  • Two-tone Exclusive Nappa Leather - A$3,000
  • Pearl Effect Paint - A$1,950
  • Power Folding Headrest - Rear - A$350
  • Panoramic Sunroof - A$3,100
  • Premium Sound System - Harmon Kardon - A$1,800
  • Premium Sound System - Bowers and Wilkins - A$4,100
  • Tinted Windows - Rear - A$700
