2021 Volkswagen Tiguan 147TDI R-LINE

2021 Volkswagen Tiguan 147TDI R-LINE Specifications

Volkswagen Logo
MRLP A$56,290
6.1L/100km
5 stars

About the 2021 Volkswagen Tiguan 147TDI R-LINE

The 2021 Volkswagen Tiguan 147TDI R-LINE is an all-wheel drive four-door wagon that was released to the Australian market on 01/06/2021 classified as a 5NA MY22. The Tiguan is regarded as a medium SUV built in Germany with prices starting at A$56,290 before on-road costs.

The Tiguan is an all-wheel drive 4 door with 5 seats, powered by a 2.0L TURBO 4 engine that has 147 kW of power (at 3600 rpm) and 400 Nm of torque (at 1750 rpm) via a Seven-speed Auto Direct Shift. VOLKSWAGEN claims the Tiguan 147TDI R-LINE uses 6.1L/100km of Diesel in the combined city and highway cycle while putting out 160g of CO2. It has a 60L fuel tank, meaning it should be able to travel 984km per full tank.

The Tiguan measures 1645mm (64.8 inches) in height, 4509mm (177.5 inches) in length, 1839mm (72.4 inches) in width with a 2681mm (105.6 inches) wheelbase that brings about a total of 1839kg (4054.3 lbs) of unladen weight. The Tiguan 147TDI R-LINE comes standard with 255/40 R20 front tyres and 255/40 R20 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2021 Volkswagen Tiguan 147TDI R-LINE has a 201mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity.

The Tiguan has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Inner Guard and the compliance plate is located on the RH Door Apert. on Lower B-Pill. An example VIN number would be similar to WVGZZZ5NZ#*123456.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Volkswagen Tiguan
Volkswagen Tiguan 147TDI R-LINE Details
PriceA$56,290
Series5NA MY22
Body Stylefour-door wagon
Release date01/06/2021
Discontinued date-
Drive typeAWD
VIN plate locationDriver Side Inner Guard
Compliance plate locationRH Door Apert. on Lower B-Pill
VIN ExampleWVGZZZ5NZ#*123456
Country of originGermany
SegmentMedium SUV
Safety ANCAP rating5 stars
Number of doors4
Seating capacity5
Volkswagen Tiguan 147TDI R-LINE Engine Specifications
TypeTURBO CDI
Size1968cc, 2.0L
Power @ RPM 147kW @ 3600rpm (197.1 hp)
Torque @ RPM400Nm @ 1750rpm (295.0 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesDUAL OVERHEAD CAM
Euro RatingEURO 6
Compression ratio16
Power/weight ratio79.9kw/tonne
Bore/stroke81mm × 95.6mm (3.2in × 3.7in)
Volkswagen Tiguan 147TDI R-LINE Drivetrain and Wheels
TransmissionSeven-speed Auto Direct Shift
Drive typeall-wheel drive
Steering typeELECTROMECHANICAL POWER STEERING
Turning circle11.9m (39.0 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size255/40 R20 - 8.5x20
Rear tyre & wheel size255/40 R20 - 8.5x20
Front suspension typeIndependent, MacPherson strut, Lower A-Arm, Anti roll bar
Rear suspension typeIndependent, 4 links, Coil Spring, Anti roll bar
Volkswagen Tiguan 147TDI R-LINE Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity60L
Fuel consumption (combined average)6.1L / 100km
Fuel consumption city (average)7.1L / 100km
Fuel consumption highway (average)5.5L / 100km
Vehicle range983.6km (611.2 miles)
Emission standardEURO 6
E10 compatible-
CO2 emissions (combined)160g / 100km
CO2 emissions (city)186g / 100km
CO2 emissions (highway)144g / 100km
Volkswagen Tiguan 147TDI R-LINE Dimensions
Length4509mm (177.5 inches)
Width1839mm (72.4 inches)
Height1645mm (64.8 inches)
Wheelbase2681mm (105.6 inches)
Front track1575mm (62.0 inches)
Rear track1564mm (61.6 inches)
Ground clearance201mm (7.9 inches)
Unladen weight1839kg (4054.3 lbs)
Gross Vehicle Mass2320kg (5114.7 lbs)
Gross Combination Mass4820kg (10626.3 lbs)
Volkswagen Tiguan 147TDI R-LINE Towing Capacity
Braked towing capacity2500kg (5511.5 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Volkswagen Tiguan 147TDI R-LINE Warranty
Warranty length60 months
Warranty distanceUnlimited km
Volkswagen Tiguan 147TDI R-LINE Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Volkswagen Tiguan 147TDI R-LINE Options
Standard Features
  • Additional 12 Volt Socket/s
  • 12 Volt Power Outlet - Load Area
  • 12 Volt Power Outlet
  • 2 Stage Unlocking - Programmable
  • 3D View
  • Climate Control - 3 Zone
  • 4Motion Active Control AWD
  • 4Motion AWD
  • Dual Front Airbags Package
  • Airbag Knee Driver
  • Anti-lock Braking
  • Automatic Climate Control Filtered
  • Adaptive Chassis Control
  • App-connect Interface
  • Apple Car Play
  • Adaptive Cruise Control
  • Automatic Door Locks - Programmable
  • Aero Wipers - Front
  • Automatic Hold Function
  • Ambient Interior Lighting
  • Adaptive Lane Guidance
  • Allergen Filter
  • Aluminium Sill Guards Illuminated
  • Anti-Slip Regulation
  • Automatic Stop/Start
  • Adjustable Steering Column
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Anti-theft Wheel Bolts
  • Android Auto
  • Audio Streaming
  • Automatic Tailgate
  • 18 Inch Alloy Wheels
  • All Weather Light Function
  • Bag Hooks
  • Brake Assist
  • Battery Energy Recuperation
  • Bottle Holders - Front and Rear
  • Black Headliner
  • Bluetooth Connectivity
  • Curtain Airbags
  • Cruise Control with Stop & Go
  • Centre Console Tray
  • Chrome Exhaust Tip(s)
  • Cup Holders - Front and Rear
  • Chrome Radiator Grille Highlights
  • Comfort Indicator Function
  • Central Locking Remote Control
  • Child Proof Rear Door Locks
  • Chrome Roof Rails
  • Child Seat Anchor Points
  • Comfort Seats Front
  • Contrast Stitching - Front Seats
  • Child Seat - ISOFIX Anchorage System
  • Chrome Side Moulding/s
  • Contrast Stitching - Rear Seats
  • Chrome Surround - Exterior Side Windows
  • Crumple Zone Front & Rear
  • Digital Audio Broadcast Radio +
  • Driver Fatigue Detection
  • Digital Cockpit
  • Dynamic Light Assist
  • Driver One Touch Lock/Unlock
  • Discover Pro Audio and Sat Nav System
  • Dust and Pollen Filter
  • Diesel Particulate Filter
  • Driving Profile Selection
  • Driver Seat Height Adjustable
  • Dynamic Cornering Lights
  • Dynamic Indicators
  • Emergency Assist
  • Easy Close Tailgate
  • Easy Open Tailgate
  • Electronic Brake Force Distribution
  • Emergency Brake Lights - Flashing
  • Electronic Differential Lock
  • Extended Electronic Differential Lock
  • Exhaust Gas Recirculation
  • Exterior Mirrors - Heated
  • Electromechanical Park Brake
  • Electro-mechanical Power Steering
  • Exterior Mirror - Reverse Tilt on Passenger Side
  • Electronic Stability Program
  • Front Air Intakes - Black
  • Front Centre Armrest - Adjustable
  • Front Centre Console Armrest Storage Box 12V plug
  • Front Centre Console Storage Area 12V plug
  • Front Footwell Lights
  • Fully Galvanised Body
  • Fog Lights - Rear
  • Fuel Filler Flap Lock/Unlock by Remote
  • Floor Mats - Front & Rear - Contrast Stitching
  • Front Assist
  • Glovebox Cooler
  • Gloss Black Rear Diffuser
  • Gesture Control
  • Grab Handles - Front and Rear
  • Headrests - Adjustable on All Seats
  • Headlights - Auto On/Off Function
  • Headlights - Coming/Leaving Home Function
  • Hill Descent Control
  • Heated Front Seats
  • Heated Steering Wheel
  • Instrument Cluster Display - 10.25 Inch
  • Instrument Cluster - Configurable
  • Illuminated Door Trim - Front
  • Illuminated Door Trim - Rear
  • Illuminated Glove Box Compartment
  • Inlays Special
  • Engine Immobiliser
  • IQ Drive
  • Intermittent Wipers - Rear
  • Keyless Access
  • Keyless Entry
  • Keyless Start
  • Lane Assist
  • Leather and Chrome Gear Lever
  • Leather Appointed Seats
  • Lane Change Assist
  • Luggage Compartment Floor - Adjustable 2 Heights
  • LED Headlights with signature DRL
  • LED Number Plate Light
  • Load Hooks
  • Low Light Sensor
  • LED Matrix Dynamic Light System
  • Lumbar Support Both Front Seats
  • Leather Steering Wheel
  • Manoeuvre Braking - Front and Rear
  • Multi Collision Brake
  • Multi-media Configurable Home Screen
  • Mirror Courtesy Lighting
  • Multi Function Display
  • Multi Function Steering Wheel
  • Multi-media System with 9.2 inch Touch Screen
  • Multi-media System with 8 inch Touch Screen
  • Map Pockets - Front & Rear
  • Media Proximity Sensor
  • Overhead Console/s
  • Occupant Protective system
  • Overhead Storage Compartment
  • Park Assist
  • Parking Bay and Parallel Parking Assistance
  • Push Button Start
  • Parking Distance Control Front & Rear
  • Paddle Shifters on Steering Wheel
  • Pedestrian Monitoring Function
  • Power front seats with memory
  • Power Lumbar Support Front Seats
  • Power Mirrors
  • Power Exterior Mirrors - Heated
  • Power Mirrors With Indicators - LED
  • Progressive Steering
  • Proximity Sensor
  • Passenger Seat Height Adjustable
  • Power Windows With One-Touch Operation
  • Power Windows with Roll-back Function
  • Rear Air Conditioning Control Panel
  • Radio AM/FM
  • Rear Air Vents
  • Rear Bumper - Chrome Highlights
  • Rear Centre Armrest with Cup Holders
  • Rear Cross Traffic Alert
  • Rear Footwell Lights
  • Rigid Safety Cell
  • Rear Lights - LED
  • R-Line Front Bumper
  • Rear Privacy Glass
  • Rear Seat Base Longitudinally Sliding
  • Rear Seat Remote Release
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear View Mirror Auto Dimming
  • Remote Window Closing
Optional Features
  • Metallic Paint - A$800
  • Pearl Effect Paint - A$800
  • Powered Panoramic Sunroof - Glass - A$2,000
  • Sound and Vision Package - A$2,500
