Home/Browse Cars/Volkswagen/Tiguan/
132 TSI R-LINE EDITION
2020 Volkswagen Tiguan 132 TSI R-LINE EDITION

2020 Volkswagen Tiguan 132 TSI R-LINE EDITION Specifications

Volkswagen Logo
7.5L/100km
5 stars

The 2020 Volkswagen Tiguan 132 TSI R-LINE EDITION is a all-wheel drive four-door wagon that was released to the Australian market on 01/09/2019 classified as a 5NA MY20. The Tiguan is regarded as a medium SUV built in Germany with prices from a dealer as a used car starting at A$41,900.

The Tiguan is an all-wheel drive 4 door with 5 seats, powered by a 2.0L TURBO 4 engine that has 132 kW of power (at 3900 rpm) and 320 Nm of torque (at 1500 rpm) via a Seven-speed Auto Direct Shift. VOLKSWAGEN claims the Tiguan 132 TSI R-LINE EDITION uses 7.5L/100km of Premium Unleaded Petrol in the combined city and highway cycle while putting out 173g of CO2. It has a 60L fuel tank, meaning it should be able to travel 800km per full tank.

The Tiguan measures 1658mm (65.3 inches) in height, 4486mm (176.6 inches) in length, 1839mm (72.4 inches) in width with a 2681mm (105.6 inches) wheelbase that brings about a total of 1600kg (5911.6 lbs) of unladen weight. The Tiguan 132 TSI R-LINE EDITION comes standard with 235/50 R19 front tyres and 235/50 R19 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2020 Volkswagen Tiguan 132 TSI R-LINE EDITION has a 201mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity.

The Tiguan has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Inner Guard and the compliance plate is located on the RH Door Apert. on Lower B-Pill. An example VIN number would be similar to VWGZZZ5NZ#W123456.


Volkswagen Tiguan 132 TSI R-LINE EDITION Details
Price-
Used Price From DealerA$41,900
Trade-In ValueA$35,600
Series5NA MY20
Body Stylefour-door wagon
Release date01/09/2019
Discontinued date31/07/2020
Drive typeAWD
VIN plate locationDriver Side Inner Guard
Compliance plate locationRH Door Apert. on Lower B-Pill
VIN ExampleVWGZZZ5NZ#W123456
Country of originGermany
SegmentMedium SUV
Safety ANCAP rating5 stars
Number of doors4
Seating capacity5
Volkswagen Tiguan 132 TSI R-LINE EDITION Engine Specifications
TypeTURBO MPFI
Size1984cc, 2.0L
Power @ RPM 132kW @ 3900rpm (177.0 hp)
Torque @ RPM320Nm @ 1500rpm (236.0 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesDUAL OVERHEAD CAM
Euro RatingEURO 6
Compression ratio11.65
Power/weight ratio82.5kw/tonne
Bore/stroke82.5mm × 92.8mm (3.2in × 3.6in)
Volkswagen Tiguan 132 TSI R-LINE EDITION Drivetrain and Wheels
TransmissionSeven-speed Auto Direct Shift
Drive typeall-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle11.5m (37.7 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size235/50 R19 - 7x19
Rear tyre & wheel size235/50 R19 - 7x19
Front suspension typeIndependent, MacPherson strut, Lower arm, Anti roll bar
Rear suspension typeIndependent, 4 links, Coil Spring, Anti roll bar
Volkswagen Tiguan 132 TSI R-LINE EDITION Fuel Specifications
Fuel typePREMIUM UNLEADED PETROL
Fuel tank capacity60L
Fuel consumption (combined average)7.5L / 100km
Fuel consumption city (average)9.2L / 100km
Fuel consumption highway (average)6.5L / 100km
Vehicle range800.0km (497.1 miles)
Emission standardEURO 6
E10 compatible-
CO2 emissions (combined)173g / 100km
CO2 emissions (city)210g / 100km
CO2 emissions (highway)150g / 100km
Volkswagen Tiguan 132 TSI R-LINE EDITION Dimensions
Length4486mm (176.6 inches)
Width1839mm (72.4 inches)
Height1658mm (65.3 inches)
Wheelbase2681mm (105.6 inches)
Front track1576mm (62.0 inches)
Rear track1566mm (61.7 inches)
Ground clearance201mm (7.9 inches)
Unladen weight1600kg (3528.0 lbs)
Gross Vehicle Mass-
Gross Combination Mass-
Volkswagen Tiguan 132 TSI R-LINE EDITION Towing Capacity
Braked towing capacity2500kg (5512.5 lbs)
Unbraked towing capacity750kg (1653.8 lbs)
Volkswagen Tiguan 132 TSI R-LINE EDITION Warranty
Warranty length60 months
Warranty distanceUnlimited km
Volkswagen Tiguan 132 TSI R-LINE EDITION Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Volkswagen Tiguan 132 TSI R-LINE EDITION Options
Standard Features
  • Additional 12 Volt Socket/s
  • 12 Volt Power Outlet
  • Climate Control - 3 Zone
  • Automatically Activated Hazard Lights
  • Dual Front Airbags Package
  • Airbag Knee Driver
  • Anti-lock Braking
  • Active Bonnet
  • Automatic Climate Control Filtered
  • Apple Car Play
  • Automatic Door Locks
  • Autonomous Emergency Braking
  • Active Info Display
  • Adjustable Speed Limiter
  • Anti-Slip Regulation
  • Anti-theft Wheel Bolts
  • Android Auto
  • 19 Inch Alloy Wheels
  • Brake Assist
  • Body Coloured Bumpers
  • Body Coloured Exterior Door Handles
  • Body Coloured Exterior Mirrors
  • Bottle Holders - Front and Rear
  • Bluetooth Connectivity
  • City Brake Support Forward
  • Chrome Front Grille
  • Cargo Net - On Floor
  • Cup Holders - Front and Rear
  • Cargo Tie Down Hooks/Rings
  • Central Locking Remote Control
  • Connect App Services
  • Child Proof Rear Door Locks
  • Chrome Roof Rails
  • Child Seat Anchor Points
  • Comfort Seats Front
  • Child Seat - ISOFIX Anchorage System
  • Chrome Surround - Exterior Side Windows
  • Cloth Trim Special
  • Collision Warning - Full Auto Brake
  • Driver Assist Pack
  • Driver Fatigue Detection
  • Driver Lumbar Support
  • Dust and Pollen Filter
  • Daytime Running Lights - LED
  • Dusk Sensing Headlights
  • Dynamic Cornering Lights
  • Dynamic Headlights
  • Emergency Assist
  • Electronic Brake Force Distribution
  • Electronic Diff Lock Rear
  • Exterior Mirrors - Heated
  • Electric Parking Brake
  • Electronic Stability Program
  • Extra USB Socket/s
  • Front Centre Armrest
  • Fog Lights - Front
  • Fog Lights - Rear
  • Floor Mats - Front & Rear
  • Glovebox Cooler
  • Headrests - Adjustable on All Seats
  • Head Airbags
  • Hill Holder
  • Hands-Free Smart Tailgate
  • Illuminated Glove Box Compartment
  • Inlays
  • Engine Immobiliser
  • Keyless Entry & Start
  • Leather Accented Gear Knob
  • Luggage/Cargo Area Light(s)
  • Lane Departure Warning
  • LED Headlights
  • Lockable Fuel Filler Cap/Lid
  • Lane Keeping Assist
  • Manoeuvre Braking
  • Multi Collision Brake
  • Memory Card Reader
  • Media Control
  • Multi Function Control Screen
  • Multi Function Steering Wheel
  • MP3 Compatible Audio/CD Player
  • Map/Reading Lights - Front & Rear
  • Navigation System
  • One Touch Convenience Turn Signal
  • Park Assist
  • Parking Distance Control Front & Rear
  • Pedestrian Recognition
  • Personal Profile
  • Power Mirrors With Folding
  • Power Mirrors With Indicators
  • Power Tailgate
  • Power Windows With One-Touch Operation
  • Rear Centre Armrest
  • Rear Lights - LED
  • R-Line Interior Pack
  • R-Line Pack
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear View Mirror Auto Dimming
  • Side Airbags
  • Side Assist
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Side Door Impact Beams
  • Sound System with 8 Speakers
  • Sunvisors with Vanity Mirrors & Illumination
  • Spare Wheel - Space Saver/Temporary
  • Traffic Jam Assist
  • Tyre Pressure Monitoring System
  • Tinted Windows
  • USB Input Socket
  • Extended Electronic Diff Lock
Optional Features
  • Metallic Paint - A$800
  • Pearl Effect Paint - A$800
  • Powered Panoramic Sunroof - A$2,000
