2022 Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR

2022 Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Specifications

Toyota Logo
MRLP $41,100
4.8L/100km
5 stars

About the 2022 Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR

The 2022 Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR is an all-wheel drive five-door wagon that was released to the Australian market on 01/12/2021 classified as a AXAH54R. The RAV4 is regarded as a medium SUV built in Japan with prices starting at $41,100 before on-road costs.

The RAV4 is an all-wheel drive 5 door with 5 seats, powered by a 2.5L INLINE 4 engine that has 131 kW of power (at 5700 rpm) and 221 Nm of torque (at 3600 rpm) via a Continuous Variable. TOYOTA claims the RAV4 GX (AWD) FSS + NAVIGATION HYBR uses 4.8L/100km of Unleaded Petrol-Electric Hybrid in the combined city and highway cycle while putting out 109g of CO2. It has a 55L fuel tank, meaning it should be able to travel 1146km per full tank.

The RAV4 measures 1685mm (66.3 inches) in height, 4600mm (181.1 inches) in length, 1855mm (73.0 inches) in width with a 2690mm (105.9 inches) wheelbase that brings about a total of 1705kg (3758.9 lbs) of unladen weight. The RAV4 GX (AWD) FSS + NAVIGATION HYBR comes standard with 225/65 R17 front tyres and 225/65 R17 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2022 Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR has a 190mm ground clearance with a 1500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 2.235.

The RAV4 has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Lower Driver Side B-Pillar. An example VIN number would be similar to JTMBW3FV10J123456.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Toyota RAV4
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Details
Price$41,100
SeriesAXAH54R
Body Stylefive-door wagon
Release date01/12/2021
Discontinued date-
Drive typeAWD
VIN plate locationDriver Side Front Floor
Compliance plate locationLower Driver Side B-Pillar
VIN ExampleJTMBW3FV10J123456
Country of originJapan
SegmentMedium SUV
Safety ANCAP rating5 stars
Number of doors5
Seating capacity5
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Engine Specifications
TypeDIRECT FUEL INJ
Size2487cc, 2.5L
Power @ RPM 131kW @ 5700rpm (175.7 hp)
Torque @ RPM221Nm @ 3600rpm (163.0 lb-ft)
Cylindersfour-cylinder
Number of Valves16
ValvesDUAL OVERHEAD CAM
Euro RatingEURO 5
Compression ratio14
Power/weight ratio76.8kw/tonne
Bore/stroke87.5mm × 103.4mm (3.4in × 4.1in)
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Drivetrain and Wheels
TransmissionContinuous Variable
Drive typeall-wheel drive
Steering typeELECTRIC POWER STEERING
Turning circle11m (36.1 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size225/65 R17 - 7Jx17
Rear tyre & wheel size225/65 R17 - 7Jx17
Front suspension typeMacPherson strut, Anti roll bar
Rear suspension typeShock absorber, Trailing arm, Trailing Wishbone, Anti roll bar
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Fuel Specifications
Fuel typeUNLEADED PETROL/ELECTRIC
Fuel tank capacity55L
Fuel consumption (combined average)4.8L / 100km
Fuel consumption city (average)5L / 100km
Fuel consumption highway (average)4.8L / 100km
Vehicle range1145.8km (712.0 miles)
Emission standardEURO 5
E10 compatible-
CO2 emissions (combined)109g / 100km
CO2 emissions (city)112g / 100km
CO2 emissions (highway)109g / 100km
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Dimensions
Length4600mm (181.1 inches)
Width1855mm (73.0 inches)
Height1685mm (66.3 inches)
Wheelbase2690mm (105.9 inches)
Front track1605mm (63.2 inches)
Rear track1625mm (64.0 inches)
Ground clearance190mm (7.5 inches)
Unladen weight1705kg (3758.9 lbs)
Gross Vehicle Mass2230kg (4916.3 lbs)
Gross Combination Mass-
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Towing Capacity
Braked towing capacity1500kg (3306.9 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Warranty
Warranty length60 months
Warranty distanceUnlimited km
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Toyota RAV4 GX (AWD) FSS + NAVIGATION HYBR Options
Standard Features
  • Five Seat Interior
  • Dual Front Airbags Package
  • Automatic Brake Hold
  • Airbag Knee Driver
  • Auto Climate Control with Dual Temp Zones
  • Active High Beam Control
  • Apple Car Play
  • Antenna - Roof-mounted Shark Fin type
  • All-speed Active Cruise Control
  • Adjustable Steering Column
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Android Auto
  • 17 Inch Alloy Wheels
  • Body Coloured Exterior Door Handles
  • Blind Spot Monitoring
  • Curtain Airbags
  • Centre Console Storage
  • Centre Console Tray
  • Cup Holders - Front and Rear
  • Child Seat - ISOFIX Anchorage System
  • Cloth Upholstery
  • Cyclist Recognition
  • Digital Audio Broadcast Radio +
  • Driver Mode Selection
  • Daytime Running Lights - LED
  • Display Screen 4.2 Inch
  • Dusk Sensing Headlights
  • Electric Motor
  • Electric Parking Brake
  • Electric Power Steering
  • Extra USB Socket/s
  • EV Mode
  • Forward Collision Warning
  • Fog Lights - LED
  • Floor Mats - Front & Rear
  • Headlights - Automatic Levelling
  • Hill Start Assist
  • Hybrid Drive System
  • Illuminated Entry
  • Engine Immobiliser
  • Lane Departure Alert
  • LED Headlights
  • LED Interior Lighting
  • Load Hooks
  • Lane Trace Control
  • Mud Flaps - Rear
  • Multi Function Steering Wheel
  • Multi Information Display
  • Multi-media System with 8 inch Touch Screen
  • Nickel Metal Hydride Battery
  • Off Road Dial
  • Off Road Mode
  • Parking Distance Control Front & Rear
  • Pedestrian Recognition
  • Projector Headlights
  • Parking Support Brake
  • Power Mirrors With Heated & Folding
  • Permanent Magnet Synchronous Motor
  • Pre-collision Systems
  • Premium Steering Wheel
  • Power Windows
  • Rear Air Vents
  • Rear Centre Armrest with Cup Holders
  • Rear Centre Armrest - Folding
  • Rear Combination Lights LED
  • Rear Cross Traffic Alert
  • Remote Entry with Smart Start
  • Rear Spoiler
  • Rain Sensing Wipers
  • Reversing Camera
  • Side Airbags - Front Seats side
  • Satellite Navigation
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Reminder for All Seats
  • SDL Media Manager
  • Split Fold Rear Seat
  • Sunglass Holder
  • Synthetic Leather Door Armrest
  • Sound System with 6 Speakers
  • Soft Touch Instrument Panel
  • Spare Wheel - Full Size Alloy Wheel
  • Spare Wheel - Space Saver/Temporary
  • Trail Mode
  • Trailer Stability Control
  • Toyota Safety Sense 2
  • Twin Tailpipes
  • USB Input Socket
  • USB Charging Port/s - Rear
  • Vinyl Gear Knob
  • Vinyl Shift Lever
  • Wheel Finish - Grey
Optional Features
  • Mica Paint - $675
  • Metallic Paint - $675
