2020 Toyota HiLux SR5 HI-RIDER Specifications
About the 2020 Toyota HiLux SR5 HI-RIDER
The 2020 Toyota HiLux SR5 HI-RIDER is a rear-wheel drive double cab pickup that was released to the Australian market on 01/05/2020 classified as a GUN136R FACELIFT. The HiLux is regarded as a pick up or cab chassis 4x2 built in Thailand with prices from a dealer as a used car starting at A$48,500.
The HiLux is a rear-wheel drive 4 door with 5 seats, powered by a 2.8L DIESEL TURBO 4 engine that has 150 kW of power (at 3000 rpm) and 500 Nm of torque (at 1600 rpm) via a Six-speed Automatic. TOYOTA claims the HiLux SR5 HI-RIDER uses 7.5L/100km of Diesel in the combined city and highway cycle while putting out 197g of CO2. It has a 80L fuel tank, meaning it should be able to travel 1067km per full tank.
The HiLux measures 1815mm (71.5 inches) in height, 5325mm (209.6 inches) in length, 1855mm (73.0 inches) in width with a 3085mm (121.5 inches) wheelbase that brings about a total of 1915kg (4221.8 lbs) of unladen weight. The HiLux SR5 HI-RIDER comes standard with 265/60 R18 front tyres and 265/60 R18 rear tyres. It requires a service every 6 months or 10,000 km, whichever comes first.
The 2020 Toyota HiLux SR5 HI-RIDER has a 216mm ground clearance with a 2800kg braked and 750kg unbraked towing capacity.
The HiLux has received a 5 star rating from ANCAP. The VIN number can be found on the Right Rear Chassis Rail and the compliance plate is located on the Pass Side Lower B-Pillar. An example VIN number would be similar to MR0JA3DD980000001.
Latest Toyota HiLux Reviews
| Toyota HiLux SR5 HI-RIDER Details | |
|---|---|
| Price | - |
| Used Price From Dealer | A$48,500 |
| Trade-In Value | A$41,700 |
| Series | GUN136R FACELIFT |
| Body Style | double cab pickup |
| Release date | 01/05/2020 |
| Discontinued date | 31/08/2021 |
| Drive type | RWD |
| VIN plate location | Right Rear Chassis Rail |
| Compliance plate location | Pass Side Lower B-Pillar |
| VIN Example | MR0JA3DD980000001 |
| Country of origin | Thailand |
| Segment | Pick Up or Cab Chassis 4X2 |
| Safety ANCAP rating | 5 stars |
| Number of doors | 4 |
| Seating capacity | 5 |
| Toyota HiLux SR5 HI-RIDER Engine Specifications | |
| Type | DIESEL TURBO F/INJ |
| Size | 2753cc, 2.8L |
| Power @ RPM | 150kW @ 3000rpm (201.2 hp) |
| Torque @ RPM | 500Nm @ 1600rpm (368.7 lb-ft) |
| Cylinders | turbocharged four-cylinder |
| Number of Valves | 16 |
| Valves | DUAL OVERHEAD CAM |
| Euro Rating | EURO 5 |
| Compression ratio | 15.6 |
| Power/weight ratio | 78.3kw/tonne |
| Bore/stroke | 92mm × 103.6mm (3.6in × 4.1in) |
| Toyota HiLux SR5 HI-RIDER Drivetrain and Wheels | |
| Transmission | Six-speed Automatic |
| Drive type | rear-wheel drive |
| Steering type | RACK & PINION - POWER ASSISTED |
| Turning circle | 11.8m (38.7 ft) |
| Brake (front) type | DISC - VENTILATED |
| Brake (rear) type | DRUM |
| Front tyre & wheel size | 265/60 R18 - 7.5x18 |
| Rear tyre & wheel size | 265/60 R18 - 7.5x18 |
| Front suspension type | Double wishbone, Coil Spring, Hydraulic double acting shock absorber, Anti roll bar |
| Rear suspension type | Leaf spring, Hydraulic double acting shock absorber |
| Toyota HiLux SR5 HI-RIDER Fuel Specifications | |
| Fuel type | DIESEL |
| Fuel tank capacity | 80L |
| Fuel consumption (combined average) | 7.5L / 100km |
| Fuel consumption city (average) | 8.9L / 100km |
| Fuel consumption highway (average) | 6.6L / 100km |
| Vehicle range | 1066.7km (662.8 miles) |
| Emission standard | EURO 5 |
| E10 compatible | - |
| CO2 emissions (combined) | 197g / 100km |
| CO2 emissions (city) | 235g / 100km |
| CO2 emissions (highway) | 175g / 100km |
| Toyota HiLux SR5 HI-RIDER Dimensions | |
| Length | 5325mm (209.6 inches) |
| Width | 1855mm (73.0 inches) |
| Height | 1815mm (71.5 inches) |
| Wheelbase | 3085mm (121.5 inches) |
| Front track | 1535mm (60.4 inches) |
| Rear track | 1550mm (61.0 inches) |
| Ground clearance | 216mm (8.5 inches) |
| Unladen weight | 1915kg (4221.8 lbs) |
| Gross Vehicle Mass | 2980kg (6569.8 lbs) |
| Gross Combination Mass | 5650kg (12456.1 lbs) |
| Toyota HiLux SR5 HI-RIDER Towing Capacity | |
| Braked towing capacity | 2800kg (6172.9 lbs) |
| Unbraked towing capacity | 750kg (1653.5 lbs) |
| Toyota HiLux SR5 HI-RIDER Warranty | |
| Warranty length | 60 months |
| Warranty distance | Unlimited km |
| Toyota HiLux SR5 HI-RIDER Servicing | |
| Service interval (km) | 10,000 km |
| Service interval (months) | 6 months |
| Toyota HiLux SR5 HI-RIDER Options | |
| Standard Features |
|
| Optional Features |
|
