2021 Ram 1500 EXPRESS (4x4) WITH RAMBOX

2021 Ram 1500 EXPRESS (4x4) WITH RAMBOX Specifications

RAM Logo
Not tested

About the 2021 Ram 1500 EXPRESS (4x4) WITH RAMBOX

The 2021 Ram 1500 EXPRESS (4x4) WITH RAMBOX is a four-wheel drive quad cab utility that was released to the Australian market on 01/01/2020 classified as a MY20. The 1500 is regarded as a pick up or cab chassis 4x4 built in United States Of America with prices from a dealer as a used car starting at A$81,100.

The 1500 is a four-wheel drive 4 door with 5 seats, powered by a 5.7L V8 engine that has 291 kW of power (at 5600 rpm) and 556 Nm of torque (at 3950 rpm) via an Eight-speed Automatic. RAM claims the 1500 EXPRESS (4x4) WITH RAMBOX uses 12.2L/100km of Unleaded Petrol in the combined city and highway cycle while putting out 283g of CO2. It has a 121L fuel tank, meaning it should be able to travel 992km per full tank.

The 1500 measures 1924mm (75.7 inches) in height, 5817mm (229.0 inches) in length, 2017mm (79.4 inches) in width with a 3569mm (140.5 inches) wheelbase that brings about a total of 2605kg (5743.0 lbs) of unladen weight. The 1500 EXPRESS (4x4) WITH RAMBOX comes standard with 275/60 R20 front tyres and 275/60 R20 rear tyres. It requires a service every 12 months or 12,000 km, whichever comes first.

The 2021 Ram 1500 EXPRESS (4x4) WITH RAMBOX has a 218mm ground clearance with a 4500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.92.

The VIN number can be found on the Mid Front Driver Chassis and the compliance plate is located on the Lower Pass Side B-Pillar. An example VIN number would be similar to 1C6RR7NT#JS223393.


There are no current reviews of this variant. Click here to see reviews for other variants of the Ram 1500
Ram 1500 EXPRESS (4x4) WITH RAMBOX Details
Used Price From DealerA$81,100
Trade-In ValueA$70,600
Body Stylequad cab utility
Release date01/01/2020
Discontinued date31/03/2021
Drive type4x4
VIN plate locationMid Front Driver Chassis
Compliance plate locationLower Pass Side B-Pillar
VIN Example1C6RR7NT#JS223393
Country of originUnited States Of America
SegmentPick Up or Cab Chassis 4X4
Safety ANCAP ratingNot tested
Number of doors4
Seating capacity5
Ram 1500 EXPRESS (4x4) WITH RAMBOX Engine Specifications
Size5654cc, 5.7L
Power @ RPM 291kW @ 5600rpm (390.2 hp)
Torque @ RPM556Nm @ 3950rpm (410.0 lb-ft)
Number of Valves16
Euro RatingEURO 5
Compression ratio10.5
Power/weight ratio111.7kw/tonne
Bore/stroke99.5mm × 90.9mm (3.9in × 3.5in)
Ram 1500 EXPRESS (4x4) WITH RAMBOX Drivetrain and Wheels
TransmissionEight-speed Automatic
Drive typefour-wheel drive
Turning circle13.9m (45.6 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size275/60 R20 - 9x20
Rear tyre & wheel size275/60 R20 - 9x20
Front suspension typeA-Arms, Coil Spring, Twin Tube Shock Absorbers, Stabiliser bar
Rear suspension type5 links, Track Bar, Twin Tube Shock Absorbers, Coil Spring, Stabiliser bar, Solid Axle
Ram 1500 EXPRESS (4x4) WITH RAMBOX Fuel Specifications
Fuel tank capacity121L
Fuel consumption (combined average)12.2L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range991.8km (616.3 miles)
Emission standardEURO 5
E10 compatible-
CO2 emissions (combined)283g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Ram 1500 EXPRESS (4x4) WITH RAMBOX Dimensions
Length5817mm (229.0 inches)
Width2017mm (79.4 inches)
Height1924mm (75.7 inches)
Wheelbase3569mm (140.5 inches)
Front track1742mm (68.6 inches)
Rear track1727mm (68.0 inches)
Ground clearance218mm (8.6 inches)
Unladen weight2605kg (5743.0 lbs)
Gross Vehicle Mass3450kg (7605.9 lbs)
Gross Combination Mass7237kg (15954.8 lbs)
Ram 1500 EXPRESS (4x4) WITH RAMBOX Towing Capacity
Braked towing capacity4500kg (9920.8 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Ram 1500 EXPRESS (4x4) WITH RAMBOX Warranty
Warranty length36 months
Warranty distanceUnlimited km
Ram 1500 EXPRESS (4x4) WITH RAMBOX Servicing
Service interval (km)12,000 km
Service interval (months)12 months
Ram 1500 EXPRESS (4x4) WITH RAMBOX Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Air Conditioning
  • Adjustable Driver Seat - Manual
  • Adjustable Passenger Seat - Manual
  • Ambient Temperature Display
  • Anti Theft Wheel Nuts
  • 20 Inch Alloy Wheels
  • Body Coloured Bumpers
  • Bucket Front Seats
  • Bench Seat Rear
  • Bluetooth Connectivity
  • Curtain Airbags
  • Chrome Bumpers
  • Cruise Control
  • Cargo Management System - Lockable with Lighting
  • Compass Display
  • Child Seat Anchor Points
  • Collapsible Steering Column
  • Cloth Trim
  • Driver Mode Selection
  • Dusk Sensing Headlights
  • Electronic Brake Force Distribution
  • Electronic Differential Lock
  • Exterior Mirrors Folding
  • Electric Power Steering
  • Fog Lights - Front
  • Floor Mats - Front & Rear
  • Heavy Duty Shock Absorbers
  • Hill Start Assist
  • Engine Immobiliser
  • Luggage/Cargo Area Light(s)
  • Locking Tailgate
  • Multi Function Control Screen
  • Multi Function Display
  • Multi Function Steering Wheel
  • Park Assist
  • Painted Grille
  • Power Exterior Mirrors - Heated
  • Power Windows Front
  • Power Windows Rear
  • Ready Alert Braking System
  • Remote Keyless Entry
  • Reversing Camera
  • Side Airbags - Front Seats side
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Storage Compartment - Centre Floor Console
  • Special Identifying Badging
  • Sound System with 6 Speakers
  • Side Steps
  • Storage Package
  • Spare Wheel - Full Size Alloy Wheel
  • Towbar
  • Trailer Brake Controls
  • Trip Computer
  • Traction Control System
  • Telematics
  • Tonneau Cover
  • Tyre Pressure Monitoring System
  • Trailer Stability Control
  • Tinted Windows
  • Ute Tray Liner
  • Vehicle Stability Control
  • Windscreen With Sunband
Optional Features
  • Metallic Paint - A$950
  • Pearl Effect Paint - A$950
