2016 Nissan Navara DX (4x4)

2016 Nissan Navara DX (4x4) Specifications

Nissan Logo
6.6L/100km
5 stars

About the 2016 Nissan Navara DX (4x4)

The 2016 Nissan Navara DX (4x4) is a four-wheel drive cab chassis that was released to the Australian market on 01/11/2015 classified as a NP300 D23. The Navara is regarded as a pick up or cab chassis 4x4 built in Thailand with prices from a dealer as a used car starting at A$19,700.

The Navara is a four-wheel drive 2 door with 2 seats, powered by a 2.3L DIESEL TURBO 4 engine that has 120 kW of power (at 3750 rpm) and 403 Nm of torque (at 1500 rpm) via a Six-speed Manual. NISSAN claims the Navara DX (4x4) uses 6.6L/100km of Diesel in the combined city and highway cycle while putting out 174g of CO2. It has a 80L fuel tank, meaning it should be able to travel 1212km per full tank.

The Navara measures 1735mm (68.3 inches) in height, 5120mm (201.6 inches) in length, 1790mm (70.5 inches) in width with a 3150mm (124.0 inches) wheelbase that brings about a total of 1604kg (3536.2 lbs) of unladen weight. The Navara DX (4x4) comes standard with 195 R15 front tyres and 195 R15 rear tyres. It requires a service every 12 months or 20,000 km, whichever comes first.

The 2016 Nissan Navara DX (4x4) has a 195mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.357.

The Navara has received a 5 star rating from ANCAP. The VIN number can be found on the and the compliance plate is located on the Lower Pass Side A-Pillar. An example VIN number would be similar to MNTDB4D23A0000011.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Nissan Navara
Nissan Navara DX (4x4) Details
Price-
Used Price From DealerA$19,700
Trade-In ValueA$15,400
SeriesNP300 D23
Body Stylecab chassis
Release date01/11/2015
Discontinued date31/10/2016
Drive type4x4
VIN plate location-
Compliance plate locationLower Pass Side A-Pillar
VIN ExampleMNTDB4D23A0000011
Country of originThailand
SegmentPick Up or Cab Chassis 4X4
Safety ANCAP rating5 stars
Number of doors2
Seating capacity2
Nissan Navara DX (4x4) Engine Specifications
TypeDIESEL TURBO F/INJ
Size2298cc, 2.3L
Power @ RPM 120kW @ 3750rpm (160.9 hp)
Torque @ RPM403Nm @ 1500rpm (297.2 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesDUAL OVERHEAD CAM
Euro Rating-
Compression ratio15.4
Power/weight ratio74.8kw/tonne
Bore/stroke85mm × 101.3mm (3.3in × 4.0in)
Nissan Navara DX (4x4) Drivetrain and Wheels
TransmissionSix-speed Manual
Drive typefour-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle11.8m (38.7 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDRUM
Front tyre & wheel size195 R15 - 5.5x15
Rear tyre & wheel size195 R15 - 5.5x15
Front suspension typeDouble wishbone, Coil Spring, Hydraulic double acting shock absorber, Anti roll bar
Rear suspension typeLeaf spring, Hydraulic double acting shock absorber
Nissan Navara DX (4x4) Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity80L
Fuel consumption (combined average)6.6L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range1212.1km (753.2 miles)
Emission standard-
E10 compatible-
CO2 emissions (combined)174g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Nissan Navara DX (4x4) Dimensions
Length5120mm (201.6 inches)
Width1790mm (70.5 inches)
Height1735mm (68.3 inches)
Wheelbase3150mm (124.0 inches)
Front track1560mm (61.4 inches)
Rear track1560mm (61.4 inches)
Ground clearance195mm (7.7 inches)
Unladen weight1604kg (3536.2 lbs)
Gross Vehicle Mass2800kg (6172.9 lbs)
Gross Combination Mass-
Nissan Navara DX (4x4) Towing Capacity
Braked towing capacity3500kg (7716.2 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Nissan Navara DX (4x4) Warranty
Warranty length36 months
Warranty distance100,000km
Nissan Navara DX (4x4) Servicing
Service interval (km)20,000 km
Service interval (months)12 months
Nissan Navara DX (4x4) Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Airbag Knee Driver
  • Anti-lock Braking
  • Air Conditioning
  • Adjustable Driver Seat - Manual
  • Adjustable Steering Wheel - Tilt Only
  • AUX/USB Input Socket
  • Brake Assist
  • Body Coloured Front Bumper
  • Bottle Holders - Front Seats
  • Cruise Control
  • Cup Holders - Front Seats
  • Collapsible Steering Column
  • Cloth Trim
  • Door Ajar Warning
  • Digital Clock
  • Door Pockets - Front Seat
  • Daytime Running Lights - LED
  • Dusk Sensing Headlights
  • Electronic Brake Force Distribution
  • Electronic Stability Program
  • Glovebox Compartment
  • Grab Handles - Front Seats
  • Head Airbags
  • Headrests - Adjustable Front Seats
  • Halogen Headlights
  • High Mounted Rear Stop Light
  • Engine Immobiliser
  • Intermittent Wipers - Variable
  • Lockable Fuel Filler Cap/Lid
  • Mud Flaps - Front
  • Multi Function Steering Wheel
  • Mobile Phone Connectivity
  • Map/Reading Lights - Front
  • Power Mirrors
  • Power Steering
  • Power Windows
  • Radio CD with 4 Speakers
  • Rear View Mirror Day/Night
  • Side Airbags
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for Front Seats
  • Storage Compartment - Centre Floor Console
  • Side Door Impact Beams
  • Sunglass Holder
  • Sunvisors with Vanity Mirrors
  • Spare Wheel - Full Size Steel Wheel
  • Steering Wheel - Urethane Type
  • Trip Computer
  • Traction Control System
  • Vinyl Floor Covering
Optional Features-
