2021 Mazda MX-30 G20E ASTINA MHEV

2021 Mazda MX-30 G20E ASTINA MHEV Specifications

Mazda Logo
MRLP A$40,990
5 stars

About the 2021 Mazda MX-30 G20E ASTINA MHEV

The 2021 Mazda MX-30 G20E ASTINA MHEV is a front-wheel drive four-door wagon that was released to the Australian market on 01/01/2021 classified as a M30A. The MX-30 is regarded as a small SUV built in Japan with prices starting at A$40,990 before on-road costs.

The MX-30 is a front-wheel drive 4 door with 5 seats, powered by a 2.0L INLINE 4 engine that has 114 kW of power (at 6000 rpm) and 200 Nm of torque (at 400 rpm) via a Six-speed Automatic. MAZDA claims the MX-30 G20E ASTINA MHEV uses 6.4L/100km of Unleaded Petrol-Electric Hybrid in the combined city and highway cycle while putting out 150g of CO2. It has a 51L fuel tank, meaning it should be able to travel 797km per full tank.

The MX-30 measures 1545mm (60.8 inches) in height, 4395mm (173.0 inches) in length, 1795mm (70.7 inches) in width with a 2655mm (104.5 inches) wheelbase that brings about a total of 1481kg (3265.0 lbs) of unladen weight. The MX-30 G20E ASTINA MHEV comes standard with 215/55 R18 95H front tyres and 215/55 R18 95H rear tyres. It requires a service every 12 months or 10,000 km, whichever comes first.

The 2021 Mazda MX-30 G20E ASTINA MHEV has a 180mm ground clearance with a 800kg braked and 600kg unbraked towing capacity. It has a final gear ratio of 4.669.

The MX-30 has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Lower Pass Side Rear Door Pill. An example VIN number would be similar to JM0DR2W7A00123456.


There are no current reviews of this variant. Click here to see reviews for other variants of the Mazda MX-30
Mazda MX-30 G20E ASTINA MHEV Details
Body Stylefour-door wagon
Release date01/01/2021
Discontinued date-
Drive typeFWD
VIN plate locationDriver Side Front Floor
Compliance plate locationLower Pass Side Rear Door Pill
VIN ExampleJM0DR2W7A00123456
Country of originJapan
SegmentSmall SUV
Safety ANCAP rating5 stars
Number of doors4
Seating capacity5
Mazda MX-30 G20E ASTINA MHEV Engine Specifications
Size1998cc, 2.0L
Power @ RPM 114kW @ 6000rpm (152.9 hp)
Torque @ RPM200Nm @ 400rpm (147.5 lb-ft)
Number of Valves16
Euro RatingEURO 5
Compression ratio13
Power/weight ratio77.0kw/tonne
Bore/stroke83.5mm × 91.2mm (3.3in × 3.6in)
Mazda MX-30 G20E ASTINA MHEV Drivetrain and Wheels
TransmissionSix-speed Automatic
Drive typefront-wheel drive
Turning circle11.4m (37.4 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size215/55 R18 95H - 7Jx18
Rear tyre & wheel size215/55 R18 95H - 7Jx18
Front suspension typeMacPherson strut
Rear suspension typeTorsion bar
Mazda MX-30 G20E ASTINA MHEV Fuel Specifications
Fuel tank capacity51L
Fuel consumption (combined average)6.4L / 100km
Fuel consumption city (average)7.6L / 100km
Fuel consumption highway (average)5.7L / 100km
Vehicle range796.9km (495.2 miles)
Emission standardEURO 5
E10 compatibleYES
CO2 emissions (combined)150g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Mazda MX-30 G20E ASTINA MHEV Dimensions
Length4395mm (173.0 inches)
Width1795mm (70.7 inches)
Height1545mm (60.8 inches)
Wheelbase2655mm (104.5 inches)
Front track1565mm (61.6 inches)
Rear track1565mm (61.6 inches)
Ground clearance180mm (7.1 inches)
Unladen weight1481kg (3265.0 lbs)
Gross Vehicle Mass-
Gross Combination Mass-
Mazda MX-30 G20E ASTINA MHEV Towing Capacity
Braked towing capacity800kg (1763.7 lbs)
Unbraked towing capacity600kg (1322.8 lbs)
Mazda MX-30 G20E ASTINA MHEV Warranty
Warranty length60 months
Warranty distanceUnlimited km
Mazda MX-30 G20E ASTINA MHEV Servicing
Service interval (km)10,000 km
Service interval (months)12 months
Mazda MX-30 G20E ASTINA MHEV Options
Standard Features
  • 12 Volt Power Outlet
  • 265mm Rear Brakes
  • 295mm Front Brakes
  • Dual Front Airbags Package
  • Automatic Brake Hold
  • Airbag Knee Driver
  • Anti-lock Braking
  • Auto Climate Control with Dual Temp Zones
  • Active Driving Display
  • Active High Beam Control
  • Apple Car Play
  • Advanced Keyless Entry
  • Advanced Keyless Push Button Engine Start
  • Adaptive LED Headlights
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Ambient Temperature Display
  • Automatic Transmission Drive Selection
  • Automatic Transmission Kickdown Switch
  • Android Auto
  • Around View Monitor
  • 18 Inch Alloy Wheels
  • Body Coloured Bumpers
  • Body Coloured Exterior Door Handles
  • Bottle Holders - Front and Rear
  • Blind Spot Monitoring
  • Bluetooth Connectivity
  • Cruising & Traffic Support
  • Curtain Airbags - Front
  • Curtain Airbags - Rear
  • Cruise Control with Stop & Go
  • Centre Console Tray
  • Centre Console with Armrest
  • Chrome Exhaust Tip(s)
  • Critical Function Warning Lights/Audible
  • Cup Holders - Front Seats
  • Cooling/Heating Vents 2nd Row
  • Central Locking Remote Control
  • Central Locking Remote Control - Additional Key
  • Convex Mirror Left Side
  • Child Proof Rear Door Locks
  • Child Seat - ISOFIX Anchorage System
  • Cyclist Recognition
  • Digital Audio Broadcast Radio +
  • Digital Amplifier
  • Driver Attention Warning
  • Drive By Wire Throttle
  • Driver Lumbar Support
  • Driver Monitoring
  • Daytime Running Lights - LED
  • Display Screen 7 Inch
  • Display Screen 8.8 Inch
  • Dynamic Stability Control
  • Driver Seat Height Adjustable
  • Emergency Brake Assist
  • Electronic Brake Force Distribution
  • Electronic Gear Selector
  • Exterior Mirrors - Auto Dimming Driver Side
  • Exterior Mirrors Tilt When Reversing
  • Electric Parking Brake
  • Electric Power Steering
  • Emergency Stop Signal
  • Front Cross Traffic Alert
  • Forward Obstruction Warning
  • Frameless Rear View Mirror
  • Freestyle Doors
  • Front Wipers 2 Speed
  • Glovebox Compartment
  • G-Vectoring Control Plus
  • Headrests - Adjustable on All Seats
  • Headlights - Auto On/Off Function
  • Handsfree Mobile Communication
  • Heated Front Seats
  • Hill Start Assist
  • High Mounted Rear Stop Light
  • Hybrid Synchronous Motor
  • Heated Steering Wheel
  • Hybrid Drive System
  • Illuminated - Entry/Exit with Delayed Fade
  • Instrument Panel Light Dimmer
  • Engine Immobiliser
  • iPod Integration
  • I-stop
  • Intermittent Wipers - Rear
  • Leather Accented and Cloth Trim
  • Luggage/Cargo Area Light(s)
  • Lane Departure Warning
  • Leather Gear Knob
  • Lithium-ion Battery
  • Lane Keeping Assist
  • Leather Steering Wheel
  • Multi Function Commander Control
  • Multi Function Steering Wheel
  • MP3 Compatibility - Bluetooth Audio
  • Map/Reading Lights - Front & Rear
  • Parking Distance Control Rear
  • Parking Distance Control Front
  • Paddle Shifters on Steering Wheel
  • Pedestrian Recognition
  • Power Front Seat Driver 10 Way + Memory
  • Power Mirrors
  • Power Mirrors With Auto Folding
  • Power Exterior Mirrors - Heated
  • Power Mirrors With Memory
  • Passenger Seat Height Adjustable
  • Power Sunroof - Glass
  • Power Windows Auto Up/Down
  • Radar Cruise Control
  • Radio AM/FM
  • Rear Centre Armrest - Folding
  • Rear Cross Traffic Alert
  • Radio Data System
  • Rear Lights - LED
  • Rear Spoiler
  • Rake & Slide Adjustment Front Seats
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear View Mirror Auto Dimming
  • Rear Window Demister
  • Rear Wiper/Washer
  • Side Airbags - 2nd Row Seats side
  • Side Airbags - Front Seats side
  • Side Airbag Centre - Driver
  • Satellite Navigation
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Load Limiters Rear Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners 2nd Row Outer
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Smart Brake Support - Rear Crossing
  • Smart Brake Support
  • Smart Brake Support - Rear
  • Side Door Impact Beams
  • Split Fold Rear Seat
  • Sunglass Holder
  • Skyactiv-Body
  • Skyactiv-Chassis
  • Skyactiv-Vehicle Dynamics
  • Seatback Pockets - Front Seats
  • Sunroof Tilt & Slide
  • Sound System with 12 Speakers
  • Sunvisors with Vanity Mirrors & Illumination
  • Spare Wheel - Space Saver/Temporary
  • Trip Computer
  • Traction Control System
  • TFT LCD Information Display
  • Tyre Pressure Monitoring System
  • Traffic Sign Recognition
  • Tinted Windshield Glass
  • Tinted Windows - Rear
  • Upholstery -Two-tone
  • USB Input Socket
  • Ventilated Front Disc Brakes
  • Wheel Finish - Bright
  • Whiplash protection System - Front Seats
Optional Features
  • 3-Tone Paint - A$995
  • 3-Tone Paint Premium - A$1,490
  • Premium Paint - A$495
