2018 Mazda CX-5 MAXX SPORT (4x4)

2018 Mazda CX-5 MAXX SPORT (4x4) Specifications

Mazda Logo
6L/100km
5 stars

About the 2018 Mazda CX-5 MAXX SPORT (4x4)

The 2018 Mazda CX-5 MAXX SPORT (4x4) is an all-wheel drive four-door wagon that was released to the Australian market on 01/04/2017 classified as a MY17.5 (KF SERIES 2). The CX-5 is regarded as a medium SUV built in Japan with prices from a dealer as a used car starting at A$29,600.

The CX-5 is an all-wheel drive 4 door with 5 seats, powered by a 2.2L DIESEL TURBO 4 engine that has 129 kW of power (at 4500 rpm) and 420 Nm of torque (at 2000 rpm) via a Six-speed Automatic. MAZDA claims the CX-5 MAXX SPORT (4x4) uses 6L/100km of Diesel in the combined city and highway cycle while putting out 158g of CO2. It has a 58L fuel tank, meaning it should be able to travel 967km per full tank.

The CX-5 measures 1675mm (65.9 inches) in height, 4550mm (179.1 inches) in length, 1840mm (72.4 inches) in width with a 2700mm (106.3 inches) wheelbase that brings about a total of 1645kg (3626.6 lbs) of unladen weight. The CX-5 MAXX SPORT (4x4) comes standard with 225/65 R17 front tyres and 225/65 R17 rear tyres. It requires a service every 12 months or 10,000 km, whichever comes first.

The 2018 Mazda CX-5 MAXX SPORT (4x4) has a 193mm ground clearance with a 1800kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 4.09.

The CX-5 has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Lower Pass Side Centre Pillar. An example VIN number would be similar to JM0KF4WLA00123456.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Mazda CX-5
Mazda CX-5 MAXX SPORT (4x4) Details
Price-
Used Price From DealerA$29,600
Trade-In ValueA$24,000
SeriesMY17.5 (KF SERIES 2)
Body Stylefour-door wagon
Release date01/04/2017
Discontinued date31/05/2018
Drive typeAWD
VIN plate locationDriver Side Front Floor
Compliance plate locationLower Pass Side Centre Pillar
VIN ExampleJM0KF4WLA00123456
Country of originJapan
SegmentMedium SUV
Safety ANCAP rating5 stars
Number of doors4
Seating capacity5
Mazda CX-5 MAXX SPORT (4x4) Engine Specifications
TypeDIESEL TURBO F/INJ
Size2191cc, 2.2L
Power @ RPM 129kW @ 4500rpm (173.0 hp)
Torque @ RPM420Nm @ 2000rpm (309.7 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesDUAL OVERHEAD CAM
Euro RatingEuro 5
Compression ratio14
Power/weight ratio78.4kw/tonne
Bore/stroke86mm × 94.3mm (3.4in × 3.7in)
Mazda CX-5 MAXX SPORT (4x4) Drivetrain and Wheels
TransmissionSix-speed Automatic
Drive typeall-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle11.2m (36.7 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size225/65 R17 - 7x17
Rear tyre & wheel size225/65 R17 - 7x17
Front suspension typeMacPherson strut, Coil Spring, Gas damper, Anti roll bar
Rear suspension typeMulti-link system, Coil Spring, Gas damper, Anti roll bar
Mazda CX-5 MAXX SPORT (4x4) Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity58L
Fuel consumption (combined average)6L / 100km
Fuel consumption city (average)7L / 100km
Fuel consumption highway (average)5.5L / 100km
Vehicle range966.7km (600.7 miles)
Emission standardEuro 5
E10 compatible-
CO2 emissions (combined)158g / 100km
CO2 emissions (city)183g / 100km
CO2 emissions (highway)144g / 100km
Mazda CX-5 MAXX SPORT (4x4) Dimensions
Length4550mm (179.1 inches)
Width1840mm (72.4 inches)
Height1675mm (65.9 inches)
Wheelbase2700mm (106.3 inches)
Front track1585mm (62.4 inches)
Rear track1590mm (62.6 inches)
Ground clearance193mm (7.6 inches)
Unladen weight1645kg (3626.6 lbs)
Gross Vehicle Mass-
Gross Combination Mass-
Mazda CX-5 MAXX SPORT (4x4) Towing Capacity
Braked towing capacity1800kg (3968.3 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Mazda CX-5 MAXX SPORT (4x4) Warranty
Warranty length36 months
Warranty distanceUnlimited km
Mazda CX-5 MAXX SPORT (4x4) Servicing
Service interval (km)10,000 km
Service interval (months)12 months
Mazda CX-5 MAXX SPORT (4x4) Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Auto Climate Control with Dual Temp Zones
  • Adjustable Driver Seat - Manual
  • Antenna - Roof-mounted Shark Fin type
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Ambient Temperature Display
  • AUX/USB Input Socket
  • 17 Inch Alloy Wheels
  • Brake Assist
  • Body Coloured Bumpers
  • Body Coloured Exterior Door Handles
  • Body Coloured Exterior Mirrors
  • Bottle Holders - Front and Rear
  • Blind Spot Monitoring
  • Bluetooth Connectivity
  • City Brake Support Forward & Reverse
  • Cruise Control
  • Chrome Exhaust Tip(s)
  • Cargo Cover
  • Cup Holders - Front and Rear
  • Centre Console Box - Multi-purpose
  • Central Locking Remote Control
  • Child Proof Rear Door Locks
  • Child Seat Anchor Points
  • Child Seat - ISOFIX Anchorage System
  • Cloth Trim
  • Cross Traffic Recognition
  • Digital Audio Broadcast Radio
  • Door Pockets - Front and Rear
  • Dynamic Stability Control
  • Dusk Sensing Headlights
  • Electronic Brake Force Distribution
  • Electric Parking Brake
  • Emergency Stop Signal
  • Fog Lights - Front
  • Glovebox Compartment
  • G-Vectoring Control Mazda
  • Headrests - Adjustable on All Seats
  • Head Airbags
  • Headlights - Auto On/Off Function
  • Hill Holder
  • High Mounted Rear Stop Light
  • Illuminated - Entry/Exit with Delayed Fade
  • Instrument Panel Light Dimmer
  • Engine Immobiliser
  • Intermittent Wipers - Variable
  • Keyless Entry and Drive
  • Luggage/Cargo Area Light(s)
  • LED Headlights
  • Leather Gear Knob
  • Leather Hand Brake Lever
  • Leather Steering Wheel
  • Multi Function Control Screen
  • Multi Function Display
  • Multi Function Steering Wheel
  • MP3 Compatible Audio/CD Player
  • Map/Reading Lights - Front
  • Parking Distance Control Rear
  • Power Mirrors With Folding
  • Power Mirrors With Indicators
  • Power Steering
  • Power Windows
  • Rear Air Vents
  • Rear Centre Armrest
  • Radio CD with 6 Speakers
  • Reclining Rear Seats
  • Remote Fuel Lid Release
  • Rear Spoiler
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear View Mirror Auto Dimming
  • Rear Window Demister
  • Rear Wiper/Washer
  • Side Airbags
  • Satellite Navigation
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Side Door Impact Beams
  • Split Fold Rear Seat
  • Sunglass Holder
  • Seatback Pockets - Front Seats
  • Start/Stop Button
  • Sunvisors with Vanity Mirrors & Illumination
  • Spare Wheel - Space Saver/Temporary
  • Trip Computer
  • Traction Control System
  • Tyre Pressure Monitoring System
  • Tinted Windows
Optional Features-
