2021 Hyundai Staria US4.V1 MY22

2021 Hyundai Staria US4.V1 MY22 Specifications

Hyundai Logo
MRLP A$51,500
8.2L/100km
Not tested

About the 2021 Hyundai Staria US4.V1 MY22

The 2021 Hyundai Staria US4.V1 MY22 is an all-wheel drive four-door wagon that was released to the Australian market on 01/06/2021 classified as a US4.V1 MY22. The Staria is regarded as a people movers up to 60k built in Korea with prices starting at A$51,500 before on-road costs.

The Staria is an all-wheel drive 4 door with 8 seats, powered by a 2.2L DIESEL TURBO 4 engine that has 130 kW of power (at 3800 rpm) and 430 Nm of torque (at 1500 rpm) via an Eight-speed Automatic. HYUNDAI claims the Staria US4.V1 MY22 uses 8.2L/100km of Diesel in the combined city and highway cycle while putting out 218g of CO2. It has a 75L fuel tank, meaning it should be able to travel 915km per full tank.

The Staria measures 1990mm (78.3 inches) in height, 5253mm (206.8 inches) in length, 1997mm (78.6 inches) in width with a 3273mm (128.9 inches) wheelbase that brings about a total of 2255kg (4971.4 lbs) of unladen weight. The Staria US4.V1 MY22 comes standard with 235/55 R18 104H front tyres and 235/55 R18 104H rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2021 Hyundai Staria US4.V1 MY22 has a 186mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.32.

The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Lower A-Pillar. An example VIN number would be similar to KMHYA811MMU000001.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Hyundai Staria
Hyundai Staria US4.V1 MY22 Details
PriceA$51,500
SeriesUS4.V1 MY22
Body Stylefour-door wagon
Release date01/06/2021
Discontinued date-
Drive typeAWD
VIN plate locationDriver Side Front Floor
Compliance plate locationPass Side Lower A-Pillar
VIN ExampleKMHYA811MMU000001
Country of originKorea
SegmentPEOPLE MOVERS UP TO 60K
Safety ANCAP ratingNot tested
Number of doors4
Seating capacity8
Hyundai Staria US4.V1 MY22 Engine Specifications
TypeTURBO CDI
Size2199cc, 2.2L
Power @ RPM 130kW @ 3800rpm (174.3 hp)
Torque @ RPM430Nm @ 1500rpm (317.1 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesDUAL OVERHEAD CAM
Euro RatingEURO 5
Compression ratio16
Power/weight ratio57.6kw/tonne
Bore/stroke85.4mm × 96mm (3.3in × 3.8in)
Hyundai Staria US4.V1 MY22 Drivetrain and Wheels
TransmissionEight-speed Automatic
Drive typeall-wheel drive
Steering typeCOLUMN MOUNTED MOTOR DRIVEN PWR STEERING
Turning circle11.94m (39.2 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC - VENTILATED
Front tyre & wheel size235/55 R18 104H - 7Jx18
Rear tyre & wheel size235/55 R18 104H - 7Jx18
Front suspension typeMacPherson strut
Rear suspension typeMulti-link system
Hyundai Staria US4.V1 MY22 Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity75L
Fuel consumption (combined average)8.2L / 100km
Fuel consumption city (average)10.4L / 100km
Fuel consumption highway (average)7L / 100km
Vehicle range914.6km (568.3 miles)
Emission standardEURO 5
E10 compatibleNO
CO2 emissions (combined)218g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Hyundai Staria US4.V1 MY22 Dimensions
Length5253mm (206.8 inches)
Width1997mm (78.6 inches)
Height1990mm (78.3 inches)
Wheelbase3273mm (128.9 inches)
Front track1721mm (67.8 inches)
Rear track1732mm (68.2 inches)
Ground clearance186mm (7.3 inches)
Unladen weight2255kg (4971.4 lbs)
Gross Vehicle Mass3040kg (6702.0 lbs)
Gross Combination Mass-
Hyundai Staria US4.V1 MY22 Towing Capacity
Braked towing capacity2500kg (5511.5 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Hyundai Staria US4.V1 MY22 Warranty
Warranty length60 months
Warranty distanceUnlimited km
Hyundai Staria US4.V1 MY22 Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Hyundai Staria US4.V1 MY22 Options
Standard Features
  • 12 Volt Power Outlet
  • 2nd Row Sliding Walk-in Device
  • 325mm Rear Brakes
  • 345mm Front Brakes
  • 4WD Lock
  • Eight Seat Interior
  • Active On-Demand 4WD
  • Dual Front Airbags Package
  • Automatic Brake Hold
  • Anti-lock Braking
  • Air Conditioning
  • Apple Car Play
  • Active Safety Group
  • AEB Junction Assist
  • Alloy Effect Interior Door Handles
  • Alloy Effect Insert - Steering Wheel
  • Alloy Effect Shift by Wire Controls
  • Auto/Intelligent Speed Limiter
  • Alarm System/Remote Anti Theft
  • Adjustable Steering Column
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Android Auto
  • Audio Streaming
  • Around View Monitor
  • 17 Inch Alloy Wheels
  • Brake Assist
  • Blind Spot Collision - Avoidance Assist - Rear
  • Body Coloured Exterior Door Handles
  • Black Door Frame & Beltline Moulding
  • Bottle Holders 3rd Row
  • Bottle Holders - Front and Rear
  • Bluetooth Connectivity - Multi-connection
  • Curtain Airbags - Front
  • Curtain Airbags - Rear
  • Cabin Air Filter
  • Configurable Active Lock/Unlock Operation
  • Cruise Control Intelligent/Active
  • Centre Console Rear Storage Drawer
  • Cruise Control with Stop & Go
  • Cupholders 3rd Row
  • Cup Holders - Front and Rear
  • Coat Hanger/Hook(s)
  • Cargo Tie Down Hooks/Rings
  • Cooling/Heating Vents 2nd Row
  • Cooling/Heating Vents 3rd Row
  • Central Locking Remote Control
  • Central Locking Tailgate
  • Comfort Mode
  • Child Proof Rear Door Locks
  • Child Seat Anchor Points
  • Child Seat - ISOFIX Anchorage System
  • Cyclist Recognition
  • Driver Attention Warning
  • Driver Mode Selection
  • Door Pockets - Front and Rear
  • Daytime Running Lights - LED
  • Dusk Sensing Headlights
  • Driver Seat Height Adjustable - Manual
  • Digital Speedometer
  • Electronic Brake Force Distribution
  • ECO Mode
  • Electronic Gear Shift Buttons
  • Electric Parking Brake
  • Electronic Stability Control
  • Emergency Stop Signal
  • Extra USB Socket/s
  • Exit Warnings System
  • Front Centre Airbag
  • Flat Fold Seating 2nd Row
  • Flat Fold Seating - 3rd Row
  • Fog Lights - LED
  • Floor Mounted Air Vents - 3rd Row
  • Front View Camera
  • Forward Collision-Avoidance Assist
  • Glovebox Compartment
  • Gloss Black Garnish - Steering Wheel Controls
  • Gloss Black Interior Garnish
  • Grab Handles - Front and Rear
  • Headrests - Adjustable on All Seats
  • High Beam Assist
  • Headlights Follow Me Home Function
  • Heated Rear Windshield
  • Hill Start Assist
  • High Mounted Rear Stop Light - LED
  • Haptic Warning Function
  • Hyundai Smartsense
  • Instrument Cluster Display - 4.2 Inch
  • Illuminated - Entry/Exit with Delayed Fade
  • Engine Immobiliser
  • Impact Sensing Auto Door Unlock
  • Keyless Remote x 2
  • LED Headlights
  • LED Light Bar
  • Lane Following Assist
  • Lane Keeping Assist - Line
  • Load Protection Net
  • Leather Steering Wheel
  • Lead Vehicle Start Alert
  • Multi Collision Brake
  • Multifaceted Reflector LED Headlights
  • Multi Function Steering Wheel
  • Multi-media System with 8 inch Touch Screen
  • Mobile Phone Connectivity
  • Map Pockets - Front & Rear
  • Manual Temperature Control
  • One Touch Directional Indicators
  • Painted Grille
  • Power Brake Assist
  • Parking Distance Control Front & Rear
  • Parking Distance Display
  • Paddle Shifters on Steering Wheel
  • Pedestrian Recognition
  • Positioning Lights LED
  • Power Mirrors With Heated & Folding
  • Power Mirrors With Auto Folding
  • Power Mirrors With Indicators - LED
  • Pop-out Latch Type Windows 2nd Row
  • Pop-out Latch Type Windows 3rd Row
  • Power Steering
  • Power Windows With One-Touch Operation
  • Power Windows Anti-trap
  • Quiet Mode Function
  • Radio AM/FM
  • Rear Cross Traffic Collision-Avoidance Assist
  • Rear Climate Control with Lockout Function
  • Rear Combination Lights LED
  • Rear LED Reverse Lamp
  • Roof Mounted Air Vents 2nd Row
  • Roof Mounted Air Vents 3rd Row
  • Roll-over Sensor
  • Rear Seatbelt Monitor
  • Rear Spoiler Tailgate Mounted
  • Reversing Camera
  • Remote Window Closing
  • Remote Window Opening
  • Rear Wiper/Washer
  • Rear Wiper Automatically Triggered in Reverse Gear
  • Side Airbags - Front Seats side
  • Seatbelt Holders 3rd Row
  • Seatbelts - Height Adjustable Front Seats
  • Seatback Hooks
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Load Limiters Rear Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Rear Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for Front Seats
  • Storage Compartment - In Dash
  • Solar Control Glass - Front Windows
  • Safety Lights Integrated In Front Doors
  • Sliding Door Courtesy Lights
  • Sports Mode
  • Smart Mode
  • Seat Occupancy Detection - Passenger (Rear)
  • Seatback Pockets - Front Seats
  • Sound System with 6 Speakers
  • Sunvisor Extensions
  • Sunvisors with Vanity Mirrors & Illumination
  • Shift by Wire Drive Selector
  • Spare Wheel - Full Size Alloy Wheel
  • Thorax Airbag - Driver
  • Thorax Airbag - Passenger
  • Trip Computer
  • Traction Control System
  • Ticket Holders - Sunvisors (both)
  • TFT LCD Instrument Cluster
  • Tyre Pressure Indicator
  • Tyre Pressure Monitoring System
  • Third Row Seats
  • Third Row Seats - Tip Up and Slide Function
  • USB Input Socket
  • USB Charging Port/s - Rear
Optional Features
  • Premium Paint - A$695
