2022 Hyundai iLoad 3S TWIN SWING

2022 Hyundai iLoad 3S TWIN SWING Specifications

Hyundai Logo
MRLP $40,230
4 stars

About the 2022 Hyundai iLoad 3S TWIN SWING

The 2022 Hyundai iLoad 3S TWIN SWING is a rear-wheel drive four-door van that was released to the Australian market on 01/06/2020 classified as a TQ4 MY21. The iLoad is regarded as a VAN 2.5-3.5t built in Korea with prices starting at $40,230 before on-road costs.

The iLoad is a rear-wheel drive 4 door with 3 seats, powered by a 2.5L DIESEL TURBO 4 engine that has 100 kW of power (at 3800 rpm) and 343 Nm of torque (at 1500 rpm) via a Six-speed Manual. HYUNDAI claims the iLoad 3S TWIN SWING uses 7.6L/100km of Diesel in the combined city and highway cycle while putting out 199g of CO2. It has a 75L fuel tank, meaning it should be able to travel 987km per full tank.

The iLoad measures 1935mm (76.2 inches) in height, 5125mm (201.8 inches) in length, 1920mm (75.6 inches) in width with a 3200mm (126.0 inches) wheelbase that brings about a total of 2084kg (4594.4 lbs) of unladen weight. The iLoad 3S TWIN SWING comes standard with 215/70 R16 front tyres and 215/70 R16 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2022 Hyundai iLoad 3S TWIN SWING has a 190mm ground clearance with a 2000kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.692.

The iLoad has received a 4 star rating from ANCAP. The VIN number can be found on the Pass Side Front Floor and the compliance plate is located on the Lower Pass Side B-Pillar. An example VIN number would be similar to KMFWBX7KLJU123456.


There are no current reviews of this variant. Click here to see reviews for other variants of the Hyundai iLoad
Hyundai iLoad 3S TWIN SWING Details
SeriesTQ4 MY21
Body Stylefour-door van
Release date01/06/2020
Discontinued date-
Drive typeRWD
VIN plate locationPass Side Front Floor
Compliance plate locationLower Pass Side B-Pillar
VIN ExampleKMFWBX7KLJU123456
Country of originKorea
SegmentVANS/CC 2.5-3.5t
Safety ANCAP rating4 stars
Number of doors4
Seating capacity3
Hyundai iLoad 3S TWIN SWING Engine Specifications
Size2497cc, 2.5L
Power @ RPM 100kW @ 3800rpm (134.1 hp)
Torque @ RPM343Nm @ 1500rpm (252.9 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
Euro RatingEURO 5
Compression ratio17.6
Power/weight ratio48.0kw/tonne
Bore/stroke91mm × 96mm (3.6in × 3.8in)
Hyundai iLoad 3S TWIN SWING Drivetrain and Wheels
TransmissionSix-speed Manual
Drive typerear-wheel drive
Turning circle11.2m (36.7 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC - VENTILATED
Front tyre & wheel size215/70 R16 - 6.5x16
Rear tyre & wheel size215/70 R16 - 6.5x16
Front suspension typeMacPherson strut, Coil Spring, Gas damper
Rear suspension typeLeaf spring, Gas damper
Hyundai iLoad 3S TWIN SWING Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity75L
Fuel consumption (combined average)7.6L / 100km
Fuel consumption city (average)9.3L / 100km
Fuel consumption highway (average)6.5L / 100km
Vehicle range986.8km (613.2 miles)
Emission standardEURO 5
E10 compatible-
CO2 emissions (combined)199g / 100km
CO2 emissions (city)199g / 100km
CO2 emissions (highway)173g / 100km
Hyundai iLoad 3S TWIN SWING Dimensions
Length5125mm (201.8 inches)
Width1920mm (75.6 inches)
Height1935mm (76.2 inches)
Wheelbase3200mm (126.0 inches)
Front track1685mm (66.3 inches)
Rear track1660mm (65.4 inches)
Ground clearance190mm (7.5 inches)
Unladen weight2084kg (4594.4 lbs)
Gross Vehicle Mass3160kg (6966.6 lbs)
Gross Combination Mass5160kg (11375.8 lbs)
Hyundai iLoad 3S TWIN SWING Towing Capacity
Braked towing capacity2000kg (4409.2 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Hyundai iLoad 3S TWIN SWING Warranty
Warranty length60 months
Warranty distance160,000km
Hyundai iLoad 3S TWIN SWING Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Hyundai iLoad 3S TWIN SWING Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Air Conditioning
  • Apple Car Play
  • Adjustable Driver Seat - Manual
  • Alarm System/Remote Anti Theft
  • Antenna - Roof-mounted Bee-sting type
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Android Auto
  • AUX/USB Input Socket
  • Bluetooth Connectivity
  • Cruise Control
  • Cup Holders - Front Seats
  • Cargo Tie Down Hooks/Rings
  • Central Locking Remote Control
  • Child Proof Rear Door Locks
  • Cloth Trim
  • Door Ajar Warning
  • Digital Clock
  • Dust & Pollen Filter
  • Diesel Particulate Filter
  • Door Pockets - Front Seat
  • Dusk Sensing Headlights
  • Electronic Brake Force Distribution
  • Electronic Stability Program
  • Glovebox Compartment
  • Grab Handles - Front Seats
  • High Mounted Rear Stop Light
  • Illuminated - Entry/Exit with Delayed Fade
  • Illuminated Ignition Key Ring
  • Engine Immobiliser
  • Intermittent Wipers - Variable
  • Keyless Entry
  • Luggage/Cargo Area Light/s
  • Multi-function Control Screen
  • Mud Flaps - Front & Rear
  • Multi-media Pack
  • Power Mirrors
  • Power Steering
  • Power Windows Front
  • Rear Wing Doors
  • Remote Fuel Lid Release
  • Rear View Mirror Day/Night
  • Rear Window Demister
  • Side Airbags
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for Driver Seat
  • Storage Compartment - In Dash
  • Side Door Impact Beams
  • Sound System with 2 Speakers
  • Sliding Side Door
  • Steering Wheel-mounted Audio Controls
  • Spare Wheel - Full Size Steel Wheel
  • Trip Computer
  • Traction Control System
  • Vinyl Floor Covering
  • Voice Recognition System
Optional Features
  • Mica Paint - $695
  • Metallic Paint - $695
