2022 Hyundai i30 N LINE Specifications

About the 2022 Hyundai i30 N LINE
The 2022 Hyundai i30 N LINE is a front-wheel drive five-door hatchback that was released to the Australian market on 01/07/2021 classified as a PD.V4 MY22. The i30 is regarded as a small up to 40k built in Czech Republic with prices starting at $31,720 before on-road costs.
The i30 is a front-wheel drive 5 door with 5 seats, powered by a 1.6L TURBO 4 engine that has 150 kW of power (at 6000 rpm) and 265 Nm of torque (at 4500 rpm) via a Seven-speed Auto Dual Clutch. HYUNDAI claims the i30 N LINE uses 7.1L/100km of Unleaded Petrol in the combined city and highway cycle while putting out 167g of CO2. It has a 50L fuel tank, meaning it should be able to travel 704km per full tank.
The i30 measures 1453mm (57.2 inches) in height, 4345mm (171.1 inches) in length, 1795mm (70.7 inches) in width with a 2650mm (104.3 inches) wheelbase that brings about a total of 1344kg (2963.0 lbs) of unladen weight. The i30 N LINE comes standard with 225/40 R18 92Y front tyres and 225/40 R18 92Y rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.
The 2022 Hyundai i30 N LINE has a 135mm ground clearance with a 1300kg braked and 600kg unbraked towing capacity. It has a final gear ratio of 3.611.
The i30 has received a 5 star rating from ANCAP. The VIN number can be found on the Rear Lower Driver Side EngBay and the compliance plate is located on the Pass Side Lower A-Pillar. An example VIN number would be similar to KMHH151CLLU123456.
Reviews
There are no current reviews of this variant. Click here to see reviews for other variants of the Hyundai i30Hyundai i30 N LINE Details | |
---|---|
Price | $31,720 |
Series | PD.V4 MY22 |
Body Style | five-door hatchback |
Release date | 01/07/2021 |
Discontinued date | - |
Drive type | FWD |
VIN plate location | Rear Lower Driver Side EngBay |
Compliance plate location | Pass Side Lower A-Pillar |
VIN Example | KMHH151CLLU123456 |
Country of origin | Czech Republic |
Segment | SMALL UP TO 40K |
Safety ANCAP rating | 5 stars |
Number of doors | 5 |
Seating capacity | 5 |
Hyundai i30 N LINE Engine Specifications | |
Type | TUR GASOLINE DIR INJ |
Size | 1591cc, 1.6L |
Power @ RPM | 150kW @ 6000rpm (201.2 hp) |
Torque @ RPM | 265Nm @ 4500rpm (195.4 lb-ft) |
Cylinders | turbocharged four-cylinder |
Number of Valves | 16 |
Valves | VARIABLE DOUBLE OVERHEAD CAM |
Euro Rating | EURO 5 |
Compression ratio | 9.5 |
Power/weight ratio | 111.6kw/tonne |
Bore/stroke | 77mm × 85.44mm (3.0in × 3.3in) |
Hyundai i30 N LINE Drivetrain and Wheels | |
Transmission | Seven-speed Auto Dual Clutch |
Drive type | front-wheel drive |
Steering type | RACK & PINION - POWER ASSISTED |
Turning circle | 10.6m (34.8 ft) |
Brake (front) type | DISC - VENTILATED |
Brake (rear) type | DISC |
Front tyre & wheel size | 225/40 R18 92Y - 7.5Jx18 +53 |
Rear tyre & wheel size | 225/40 R18 92Y - 7.5Jx18 +53 |
Front suspension type | MacPherson strut |
Rear suspension type | Multi-link system |
Hyundai i30 N LINE Fuel Specifications | |
Fuel type | UNLEADED PETROL |
Fuel tank capacity | 50L |
Fuel consumption (combined average) | 7.1L / 100km |
Fuel consumption city (average) | 9.4L / 100km |
Fuel consumption highway (average) | 5.9L / 100km |
Vehicle range | 704.2km (437.6 miles) |
Emission standard | EURO 5 |
E10 compatible | YES |
CO2 emissions (combined) | 167g / 100km |
CO2 emissions (city) | 220g / 100km |
CO2 emissions (highway) | 137g / 100km |
Hyundai i30 N LINE Dimensions | |
Length | 4345mm (171.1 inches) |
Width | 1795mm (70.7 inches) |
Height | 1453mm (57.2 inches) |
Wheelbase | 2650mm (104.3 inches) |
Front track | 1549mm (61.0 inches) |
Rear track | 1563mm (61.5 inches) |
Ground clearance | 135mm (5.3 inches) |
Unladen weight | 1344kg (2963.0 lbs) |
Gross Vehicle Mass | 1880kg (4144.7 lbs) |
Gross Combination Mass | - |
Hyundai i30 N LINE Towing Capacity | |
Braked towing capacity | 1300kg (2866.0 lbs) |
Unbraked towing capacity | 600kg (1322.8 lbs) |
Hyundai i30 N LINE Warranty | |
Warranty length | 60 months |
Warranty distance | Unlimited km |
Hyundai i30 N LINE Servicing | |
Service interval (km) | 15,000 km |
Service interval (months) | 12 months |
Hyundai i30 N LINE Options | |
