2021 Hyundai i30 N LINE

2021 Hyundai i30 N LINE Specifications

Hyundai Logo
MRLP A$30,290
7.5L/100km

About the 2021 Hyundai i30 N LINE

The 2021 Hyundai i30 N LINE is a front-wheel drive four-door sedan that was released to the Australian market on 01/11/2020 classified as a CN7.V1 MY21. The i30 is regarded as a small up to 40k built in Korea with prices starting at A$30,290 before on-road costs.

The i30 is a front-wheel drive 4 door with 5 seats, powered by a 1.6L TURBO 4 engine that has 150 kW of power (at 6000 rpm) and 265 Nm of torque (at 1500 rpm) via a Six-speed Manual. HYUNDAI claims the i30 N LINE uses 7.5L/100km of Unleaded Petrol in the combined city and highway cycle while putting out 174g of CO2. It has a 47L fuel tank, meaning it should be able to travel 627km per full tank.

The i30 measures 1430mm (56.3 inches) in height, 4675mm (184.1 inches) in length, 1825mm (71.9 inches) in width with a 2720mm (107.1 inches) wheelbase that brings about a total of 1310kg (2888.1 lbs) of unladen weight. The i30 N LINE comes standard with 235/40 R18 95Y XL front tyres and 235/40 R18 95Y XL rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2021 Hyundai i30 N LINE has a 140mm ground clearance with a 1200kg braked and 610kg unbraked towing capacity. It has a final gear ratio of 4.467.

The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Lower A-Pillar. An example VIN number would be similar to KMHLL41FLLU123456.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Hyundai i30
Hyundai i30 N LINE Details
PriceA$30,290
SeriesCN7.V1 MY21
Body Stylefour-door sedan
Release date01/11/2020
Discontinued date-
Drive typeFWD
VIN plate locationDriver Side Front Floor
Compliance plate locationPass Side Lower A-Pillar
VIN ExampleKMHLL41FLLU123456
Country of originKorea
SegmentSMALL UP TO 40K
Safety ANCAP rating-
Number of doors4
Seating capacity5
Hyundai i30 N LINE Engine Specifications
TypeTUR GASOLINE DIR INJ
Size1598cc, 1.6L
Power @ RPM 150kW @ 6000rpm (201.2 hp)
Torque @ RPM265Nm @ 1500rpm (195.4 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
ValvesVARIABLE DOUBLE OVERHEAD CAM
Euro RatingEURO 5
Compression ratio10
Power/weight ratio114.5kw/tonne
Bore/stroke75.6mm × 89.0mm (3.0in × 3.5in)
Hyundai i30 N LINE Drivetrain and Wheels
TransmissionSix-speed Manual
Drive typefront-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle10.8m (35.4 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size235/40 R18 95Y XL - 8Jx18 +56
Rear tyre & wheel size235/40 R18 95Y XL - 8Jx18 +56
Front suspension typeMacPherson strut
Rear suspension typeMulti-link system
Hyundai i30 N LINE Fuel Specifications
Fuel typeUNLEADED PETROL
Fuel tank capacity47L
Fuel consumption (combined average)7.5L / 100km
Fuel consumption city (average)10.3L / 100km
Fuel consumption highway (average)5.9L / 100km
Vehicle range626.7km (389.4 miles)
Emission standardEURO 5
E10 compatibleYES
CO2 emissions (combined)174g / 100km
CO2 emissions (city)238g / 100km
CO2 emissions (highway)137g / 100km
Hyundai i30 N LINE Dimensions
Length4675mm (184.1 inches)
Width1825mm (71.9 inches)
Height1430mm (56.3 inches)
Wheelbase2720mm (107.1 inches)
Front track1566mm (61.7 inches)
Rear track1581mm (62.2 inches)
Ground clearance140mm (5.5 inches)
Unladen weight1310kg (2888.1 lbs)
Gross Vehicle Mass1820kg (4012.4 lbs)
Gross Combination Mass-
Hyundai i30 N LINE Towing Capacity
Braked towing capacity1200kg (2645.5 lbs)
Unbraked towing capacity610kg (1344.8 lbs)
Hyundai i30 N LINE Warranty
Warranty length60 months
Warranty distanceUnlimited km
Hyundai i30 N LINE Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Hyundai i30 N LINE Options
Standard Features
  • 262mm Rear Brakes
  • 305mm Front Brakes
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Auto Climate Control with Dual Temp Zones
  • Apple Car Play
  • Auto Defog System
  • Autonomous Emergency Braking
  • AEB Junction Assist
  • Alarm System/Remote Anti Theft
  • Alloy Sports Pedals
  • Adjustable Steering Column
  • Adjustable Steering Wheel - Tilt & Telescopic
  • Android Auto
  • Audio Streaming
  • 18 Inch Alloy Wheels
  • Brake Assist
  • Black Beltline
  • Bottle Holders - Front and Rear
  • Black Headliner
  • Blind Spot Collision Warning
  • Bluetooth Connectivity
  • Curtain Airbags - Front
  • Curtain Airbags - Rear
  • Cabin Air Filter
  • Configurable Active Lock/Unlock Operation
  • Cruise Control
  • Centre Courtesy/Dome Light(s)
  • Chrome Exhaust Tip(s)
  • Cup Holders - Front and Rear
  • Coat Hanger/Hook(s)
  • Central Locking Remote Control
  • Child Proof Rear Door Locks
  • Child Seat Anchor Points
  • Child Seat - ISOFIX Anchorage System
  • Cyclist Recognition
  • Driver Attention Warning
  • Door Handle Courtesy Lights
  • Door Pockets - Front Seat
  • Daytime Running Lights - LED
  • Dusk Sensing Headlights
  • Driver Seat Height Adjustable
  • Digital Speedometer
  • Dual Exhaust Tips
  • Electronic Brake Force Distribution
  • Exclusive Front Bumper
  • Electric Parking Brake
  • Exclusive Rear Bumper
  • Extended Seat Bolsters - Front Seats
  • Electronic Stability Control
  • Exclusive Sports Gear Knob
  • Emergency Stop Signal
  • Exclusive Sports Steering Wheel
  • Extra USB Socket/s
  • Exit Warnings System
  • Exclusive Lip Spoiler
  • Exclusive Rear Diffuser
  • Front Centre Console Storage Area 12V plug
  • Forward Collision-Avoidance Assist
  • Glovebox Compartment
  • Gloss Black Exterior Mirrors
  • Gloss Black Inserts - Front Grille
  • Grab Handle - Passenger Side
  • Grab Handles - Rear Seats
  • Headrests - Adjustable on All Seats
  • High Beam Assist
  • Headlights Follow Me Home Function
  • Hands-Free Smart Boot Lid
  • Head Restraints
  • Heated Rear Windshield
  • Hill Start Assist
  • Hyundai Smartsense
  • Instrument Cluster Display - 4.2 Inch
  • Illuminated - Entry/Exit with Delayed Fade
  • Engine Immobiliser
  • Impact Sensing Auto Door Unlock
  • Leather Appointed Gear Knob
  • Leather Appointed Steering Wheel
  • Leather Appointed Seats
  • Luggage/Cargo Area Light(s)
  • LED Headlights
  • Lane Following Assist
  • Lane Keeping Assist - Line
  • Multi Function Steering Wheel
  • Multi-media System with 8 inch Touch Screen
  • Mobile Phone Connectivity
  • Map Pocket/s
  • Map/Reading Lights - Front
  • Manual Speed Limit Assist
  • One Touch Directional Indicators
  • Push Button Start
  • Pedestrian Recognition
  • Projector Headlights
  • Painted Inserts - Interior Door Handles
  • Painted Inserts - Steering Wheel
  • Positioning Lights LED
  • Power Mirrors With Auto Folding
  • Power Exterior Mirrors - Heated
  • Power Mirrors With Indicators - LED
  • Power Steering
  • Power Windows
  • Power Windows - Driver With One-Touch Operation
  • Power Windows Anti-trap - Driver
  • Radio AM/FM
  • Rear Air Vents
  • Rear Centre Armrest with Cup Holders
  • Rear Centre Armrest - Folding
  • Rear Combination Lights LED
  • Rear Cross Traffic Alert
  • Radio Data System
  • Remote Engine Start System
  • Rear LED Reverse Lamp
  • Red Stitching on Seats
  • Red Stitching on Gear Knob
  • Red Stitching on Gear Shift Boot
  • Red Stitching on Steering Wheel
  • Rain Sensing Wipers
  • Reversing Camera
  • Rear View Monitor
  • Side Airbags - Front Seats side
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for All Seats
  • Split Fold Rear Seat
  • Smart Key
  • Side Skirts - Black
  • Seat Occupancy Detection - Passenger (Rear)
  • Seatback Pocket - Front Passenger Seat
  • Sports Seats - Front
  • Sound System with 6 Speakers
  • Sunvisors with Vanity Mirrors & Illumination
  • Spare Wheel - Space Saver/Temporary
  • Thorax Airbag - Driver
  • Thorax Airbag - Passenger
  • Trip Computer
  • Traction Control System
  • Ticket Holders - Sunvisors (both)
  • TFT LCD Instrument Cluster
  • Tyre Pressure Monitoring System
  • USB Input Socket
  • Ventilated Front Disc Brakes
  • Vehicle Stability Management System
  • Wireless Charging Pad
  • Welcome Lights - Headlights
Optional Features
  • Mica Paint - A$495
  • Metallic Paint - A$495
