2013 Hyundai i20 ACTIVE

2013 Hyundai i20 ACTIVE Specifications

Hyundai Logo
5.9L/100km
5 stars

About the 2013 Hyundai i20 ACTIVE

The 2013 Hyundai i20 ACTIVE is a front-wheel drive three-door hatchback that was released to the Australian market on 01/06/2013 classified as a PB MY14. The i20 is regarded as a light car built in India with prices from a dealer as a used car starting at A$7,100.

The i20 is a front-wheel drive 3 door with 5 seats, powered by a 1.4L INLINE 4 engine that has 73 kW of power (at 5500 rpm) and 136 Nm of torque (at 4200 rpm) via a Four-speed Automatic. HYUNDAI claims the i20 ACTIVE uses 5.9L/100km of Unleaded Petrol in the combined city and highway cycle while putting out 140g of CO2. It has a 45L fuel tank, meaning it should be able to travel 763km per full tank.

The i20 measures 1490mm (58.7 inches) in height, 3940mm (155.1 inches) in length, 1710mm (67.3 inches) in width with a 2525mm (99.4 inches) wheelbase that brings about a total of 1100kg (2425.1 lbs) of unladen weight. The i20 ACTIVE comes standard with 175/70 R14 front tyres and 175/70 R14 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2013 Hyundai i20 ACTIVE has a 150mm ground clearance with a 1000kg braked and 450kg unbraked towing capacity.

The i20 has received a 5 star rating from ANCAP. The VIN number can be found on the Pass Side Under Front Seat and the compliance plate is located on the Lower Pass Side A-Pillar. An example VIN number would be similar to MALBA31CLAM123456.


Reviews

There are no current reviews of this variant. Click here to see reviews for other variants of the Hyundai i20
Hyundai i20 ACTIVE Details
Price-
Used Price From DealerA$7,100
Trade-In ValueA$5,000
SeriesPB MY14
Body Stylethree-door hatchback
Release date01/06/2013
Discontinued date31/08/2015
Drive typeFWD
VIN plate locationPass Side Under Front Seat
Compliance plate locationLower Pass Side A-Pillar
VIN ExampleMALBA31CLAM123456
Country of originIndia
SegmentLight Car
Safety ANCAP rating5 stars
Number of doors3
Seating capacity5
Hyundai i20 ACTIVE Engine Specifications
TypeMULTI POINT F/INJ
Size1396cc, 1.4L
Power @ RPM 73kW @ 5500rpm (97.9 hp)
Torque @ RPM136Nm @ 4200rpm (100.3 lb-ft)
Cylindersfour-cylinder
Number of Valves16
ValvesVARIABLE DOUBLE OVERHEAD CAM
Euro Rating-
Compression ratio10.5
Power/weight ratio66.4kw/tonne
Bore/stroke77mm × 74.99mm (3.0in × 2.9in)
Hyundai i20 ACTIVE Drivetrain and Wheels
TransmissionFour-speed Automatic
Drive typefront-wheel drive
Steering typeRACK & PINION - POWER ASSISTED
Turning circle10.4m (34.1 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size175/70 R14 - 5.5x14
Rear tyre & wheel size175/70 R14 - 5.5x14
Front suspension typeMacPherson strut, Coil Spring, Hydraulic double acting shock absorber, Anti roll bar
Rear suspension typeTorsion bar, Coil Spring, Hydraulic double acting shock absorber, Anti roll bar
Hyundai i20 ACTIVE Fuel Specifications
Fuel typeUNLEADED PETROL
Fuel tank capacity45L
Fuel consumption (combined average)5.9L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range762.7km (473.9 miles)
Emission standard-
E10 compatible-
CO2 emissions (combined)140g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Hyundai i20 ACTIVE Dimensions
Length3940mm (155.1 inches)
Width1710mm (67.3 inches)
Height1490mm (58.7 inches)
Wheelbase2525mm (99.4 inches)
Front track1493mm (58.8 inches)
Rear track1491mm (58.7 inches)
Ground clearance150mm (5.9 inches)
Unladen weight1100kg (2425.1 lbs)
Gross Vehicle Mass1565kg (3450.2 lbs)
Gross Combination Mass-
Hyundai i20 ACTIVE Towing Capacity
Braked towing capacity1000kg (2204.6 lbs)
Unbraked towing capacity450kg (992.1 lbs)
Hyundai i20 ACTIVE Warranty
Warranty length60 months
Warranty distanceUnlimited km
Hyundai i20 ACTIVE Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Hyundai i20 ACTIVE Options
Standard Features
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Air Conditioning
  • Adjustable Driver Seat - Manual
  • Alarm System/Remote Anti Theft
  • Antenna - Roof-mounted Bee-sting type
  • Adjustable Steering Wheel - Tilt & Telescopic
  • AUX/USB Input Socket
  • Brake Assist
  • Body Coloured Bumpers
  • Body Coloured Exterior Door Handles
  • Body Coloured Exterior Mirrors
  • Cup Holders - Front Seats
  • Cargo Tie Down Hooks/Rings
  • Chrome Interior Door Handles
  • Central Locking Remote Control
  • Child Seat Anchor Points
  • Child Seat - ISOFIX Anchorage System
  • Cloth Trim
  • Door Ajar Warning
  • Door Pockets - Front Seat
  • Electronic Brake Force Distribution
  • Electronic Stability Program
  • Glovebox Cooler
  • Headrests - Adjustable on All Seats
  • Head Airbags
  • High Mounted Rear Stop Light
  • Illuminated - Entry/Exit with Delayed Fade
  • Illuminated Glove Box Compartment
  • Engine Immobiliser
  • Luggage/Cargo Area Light(s)
  • MP3 Compatible Audio/CD Player
  • Mobile Phone Connectivity
  • Map/Reading Lights - Front
  • Power Mirrors With Indicators & Folding
  • Power Steering
  • Power Windows
  • Radio CD with 4 Speakers
  • Rear View Mirror Day/Night
  • Rear Wiper/Washer
  • Seatbelts - Height Adjustable Front Seats
  • Seatbelts - Load Limiters Front Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Front Seats
  • Seatbelts - Reminder for Front Seats
  • Storage Compartment - In Dash
  • Side Door Impact Beams
  • Speed Sensing Auto Door Lock
  • Side Front AirBags
  • Split Fold Rear Seat
  • Seatback Pockets - Front Seats
  • Sunvisors with Vanity Mirrors
  • Spare Wheel - Full Size Steel Wheel
  • Trip Computer
  • Traction Control System
Optional Features
  • Metallic Paint - A$495
