2022 GWM Cannon CANNON-L (4x4)

2022 GWM Cannon CANNON-L (4x4) Specifications

GWM Logo
MRLP $42,490
5 stars

About the 2022 GWM Cannon CANNON-L (4x4)

The 2022 GWM Cannon CANNON-L (4x4) is a four-wheel drive dual cab utility that was released to the Australian market on 01/08/2021 classified as a . The Cannon is regarded as a pick up or cab chassis 4x4 built in China with prices starting at $42,490 before on-road costs.

The Cannon is a four-wheel drive 4 door with 5 seats, powered by a 2.0L DIESEL TURBO 4 engine that has 120 kW of power (at 3600 rpm) and 400 Nm of torque (at 1500 rpm) via an Eight-speed Automatic. GWM claims the Cannon CANNON-L (4x4) uses 9.4L/100km of Diesel in the combined city and highway cycle while putting out 246g of CO2. It has a 0L fuel tank.

The Cannon measures 1886mm (74.3 inches) in height, 5410mm (213.0 inches) in length, 1934mm (76.1 inches) in width with a 3230mm (127.2 inches) wheelbase that brings about a total of 1965kg (4332.1 lbs) of unladen weight. The Cannon CANNON-L (4x4) comes standard with 265/60 R18 front tyres and 265/60 R18 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2022 GWM Cannon CANNON-L (4x4) has a 194mm ground clearance with a 3000kg braked and 750kg unbraked towing capacity.

The Cannon has received a 5 star rating from ANCAP. The VIN number can be found on the Front Driver Side Chassis and the compliance plate is located on the Pass Side Lower A-Pillar. An example VIN number would be similar to LGWDCF19#LA123456.


There are no current reviews of this variant. Click here to see reviews for other variants of the GWM Cannon
GWM Cannon CANNON-L (4x4) Details
Body Styledual cab utility
Release date01/08/2021
Discontinued date-
Drive type4x4
VIN plate locationFront Driver Side Chassis
Compliance plate locationPass Side Lower A-Pillar
VIN ExampleLGWDCF19#LA123456
Country of originChina
SegmentPick Up or Cab Chassis 4X4
Safety ANCAP rating5 stars
Number of doors4
Seating capacity5
GWM Cannon CANNON-L (4x4) Engine Specifications
Size1996cc, 2.0L
Power @ RPM 120kW @ 3600rpm (160.9 hp)
Torque @ RPM400Nm @ 1500rpm (295.0 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
Euro Rating-
Compression ratio16.2
Power/weight ratio61.1kw/tonne
GWM Cannon CANNON-L (4x4) Drivetrain and Wheels
TransmissionEight-speed Automatic
Drive typefour-wheel drive
Turning circle13.1m (43.0 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC - VENTILATED
Front tyre & wheel size265/60 R18 - 7.5Jx18
Rear tyre & wheel size265/60 R18 - 7.5Jx18
Front suspension typeDouble wishbone
Rear suspension typeLeaf spring
GWM Cannon CANNON-L (4x4) Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity-
Fuel consumption (combined average)9.4L / 100km
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range-
Emission standard-
E10 compatible-
CO2 emissions (combined)246g / 100km
CO2 emissions (city)276g / 100km
CO2 emissions (highway)228g / 100km
GWM Cannon CANNON-L (4x4) Dimensions
Length5410mm (213.0 inches)
Width1934mm (76.1 inches)
Height1886mm (74.3 inches)
Wheelbase3230mm (127.2 inches)
Front track1580mm (62.2 inches)
Rear track1580mm (62.2 inches)
Ground clearance194mm (7.6 inches)
Unladen weight1965kg (4332.1 lbs)
Gross Vehicle Mass3070kg (6768.2 lbs)
Gross Combination Mass5555kg (12246.7 lbs)
GWM Cannon CANNON-L (4x4) Towing Capacity
Braked towing capacity3000kg (6613.9 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
GWM Cannon CANNON-L (4x4) Warranty
Warranty length84 months
Warranty distanceUnlimited km
GWM Cannon CANNON-L (4x4) Servicing
Service interval (km)15,000 km
Service interval (months)12 months
GWM Cannon CANNON-L (4x4) Options
Standard Features
  • 12 Volt Power Outlet
  • 220V Power Outlet
  • 316mm Front Brakes
  • 323mm Rear Brakes
  • 4L Mode
  • Dual Front Airbags Package
  • Automatic Brake Hold
  • Automatic Air Con / Climate Control
  • Apple Car Play
  • Automatic Door Locks
  • Autonomous Emergency Braking
  • Antenna - Roof-mounted Shark Fin type
  • Anti-Slip Regulation
  • Adjustable Steering Wheel - Tilt Only
  • Adjustable Steering Column
  • Android Auto
  • Around View Monitor
  • 18 Inch Alloy Wheels
  • Brake Assist
  • Body Coloured Bumpers
  • Body Coloured Wheel Arch Flares
  • Black Interior
  • Bluetooth Connectivity
  • Curtain Airbags
  • Cargo Ladder
  • Cruise Control
  • Chrome Exterior Door Handles
  • Centre Courtesy/Dome Light/s
  • Central Differential with Lock Function
  • Chrome Exterior Mirrors
  • Chrome Front Grille
  • Central Locking Remote Control
  • Child Proof Rear Door Locks
  • Child Seat Anchor Points
  • Child Seat - ISOFIX Anchorage System
  • Cyclist Recognition
  • Door Ajar Warning
  • Diff Lock Rear
  • Driver Mode Selection
  • Dust & Pollen Filter
  • Daytime Running Lights
  • Dynamic Steering Torque System
  • Easy Close Tailgate
  • Easy Open Tailgate
  • Emergency Brake Lights - Flashing
  • ECO Mode
  • Electronic Diff Lock Rear
  • Emergency Fuel Supply Cut-Off
  • Electronic Gear Selector
  • Engine Cover
  • Electric Parking Brake
  • Electric Power Steering
  • Electronic Stability Control
  • Electronic Stability Program
  • Extra USB Socket/s
  • Front Centre Airbag
  • Forward Collision Warning
  • Fog Lights - Front with Cornering Function
  • Fog Lights - Rear
  • Headlights - Automatic Levelling
  • Headlights - Auto On/Off Function
  • Hill Descent Control
  • Handsfree Mobile Communication
  • Headlights Follow Me Home Function
  • Heated Front Seats
  • Headrests Front
  • Headrests Rear
  • Hill Start Assist
  • High Mounted Rear Stop Light
  • Hydraulic Engine Mount
  • Instrument Cluster Display - 3.5 Inch
  • Instrument Panel Light Dimmer
  • Engine Immobiliser
  • Impact Sensing Auto Door Unlock
  • Keyless Entry
  • Lane Change Assist
  • Lane Departure Warning
  • LED Headlights
  • LED Indicators
  • Lane Keeping Assist
  • Leather Steering Wheel
  • Multi-function Control Screen
  • Multi-function Steering Wheel
  • NCAP Frame & Body Structure
  • Normal Key
  • Push Button Start
  • Parking Distance Control Front & Rear
  • Paddle Shifters on Steering Wheel
  • Pedestrian Recognition
  • Power Front Seat Driver 6 Way
  • Power Mirrors With Folding
  • Power Mirrors With Indicators
  • Passenger Seat Manual Adjust 4 Way
  • Power Windows
  • Power Windows - Driver With One-Touch Operation
  • Power Windows - Anti-trap - Driver
  • Radio AM/FM
  • Rear Air Vents
  • Rear Lights - LED
  • Rear Privacy Glass
  • Rear Recovery Point
  • Rear View Mirror - Auto Dimming
  • Rear Window Demister
  • Side Airbags
  • Special Anti-rust Protection
  • Seatbelts - Load Limiters Rear Seats
  • Seatbelts - Lap/Sash for All Seats
  • Seatbelts - Pre-tensioners Rear Seats
  • Seatbelts - Reminder for Front Seats
  • Sports Bar - Stainless Steel
  • Secondary Collision Mitigation
  • Surround Camera System
  • Speed Sensing Auto Door Lock
  • Sunglass Holder
  • Smart Key
  • Speed Limit Warning - Adjustable
  • Sports Mode
  • Scuff Plates On Door Sills
  • Speed Limit Information
  • Sound System with 6 Speakers
  • Side Steps
  • Standard Mode
  • Standard Interior
  • Traction Control System
  • Touchscreen LCD 9.0 Inch
  • Torque On Demand 4x4
  • Tyre Pressure Monitoring System
  • Traffic Sign Recognition
  • Upholstery - Comfort-Tek Leather
  • USB Input Socket
  • USB Charging Port/s - Rear
  • Ventilated Front Disc Brakes
  • Ventilated Rear Disc Brakes
  • Vehicle Stability Control
  • Warning Triangle
Optional Features-
