2015 Ford Transit 470E LWB JUMBO (DRW)

2015 Ford Transit 470E LWB JUMBO (DRW) Specifications

Ford Logo
Not tested

About the 2015 Ford Transit 470E LWB JUMBO (DRW)

The 2015 Ford Transit 470E LWB JUMBO (DRW) is a rear-wheel drive five-door van that was released to the Australian market on 01/09/2015 classified as a VO MY16. The Transit is regarded as a van built in Germany with prices from a dealer as a used car starting at A$27,800.

The Transit is a rear-wheel drive 5 door with 3 seats, powered by a 2.2L DIESEL TURBO 4 engine that has 114 kW of power (at 3500 rpm) and 385 Nm of torque (at 1600 rpm) via a Six-speed Manual. It has a 100L fuel tank.

The Transit measures 2781mm (109.5 inches) in height, 5975mm (235.2 inches) in length, 2224mm (87.6 inches) in width with a 3750mm (147.6 inches) wheelbase that brings about a total of 2565kg (5654.9 lbs) of unladen weight. The Transit 470E LWB JUMBO (DRW) comes standard with 195/75 R16 front tyres and 195/75 R16 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first.

The 2015 Ford Transit 470E LWB JUMBO (DRW) has a 119mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 4.1.

The VIN number can be found on the Driver Side Front Wheel Arch and the compliance plate is located on the Pass Side Front Floor. An example VIN number would be similar to WF0XXXTTGXEL00001.


There are no current reviews of this variant. Click here to see reviews for other variants of the Ford Transit
Ford Transit 470E LWB JUMBO (DRW) Details
Used Price From DealerA$27,800
Trade-In ValueA$22,500
SeriesVO MY16
Body Stylefive-door van
Release date01/09/2015
Discontinued date31/08/2016
Drive typeRWD
VIN plate locationDriver Side Front Wheel Arch
Compliance plate locationPass Side Front Floor
Country of originGermany
Safety ANCAP ratingNot tested
Number of doors5
Seating capacity3
Ford Transit 470E LWB JUMBO (DRW) Engine Specifications
Size2198cc, 2.2L
Power @ RPM 114kW @ 3500rpm (152.9 hp)
Torque @ RPM385Nm @ 1600rpm (283.9 lb-ft)
Cylindersturbocharged four-cylinder
Number of Valves16
Euro Rating-
Compression ratio15.5
Power/weight ratio44.4kw/tonne
Bore/stroke86mm × 94.6mm (3.4in × 3.7in)
Ford Transit 470E LWB JUMBO (DRW) Drivetrain and Wheels
TransmissionSix-speed Manual
Drive typerear-wheel drive
Turning circle13.3m (43.6 ft)
Brake (front) typeDISC - VENTILATED
Brake (rear) typeDISC
Front tyre & wheel size195/75 R16 - 6x16
Rear tyre & wheel size195/75 R16 - 6x16
Front suspension typeMacPherson strut, Coil Spring, Hydraulic double acting shock absorber
Rear suspension typeLeaf spring, Hydraulic double acting shock absorber
Ford Transit 470E LWB JUMBO (DRW) Fuel Specifications
Fuel typeDIESEL
Fuel tank capacity100L
Fuel consumption (combined average)-
Fuel consumption city (average)-
Fuel consumption highway (average)-
Vehicle range-
Emission standard-
E10 compatible-
CO2 emissions (combined)213g / 100km
CO2 emissions (city)-
CO2 emissions (highway)-
Ford Transit 470E LWB JUMBO (DRW) Dimensions
Length5975mm (235.2 inches)
Width2224mm (87.6 inches)
Height2781mm (109.5 inches)
Wheelbase3750mm (147.6 inches)
Front track1732mm (68.2 inches)
Rear track1743mm (68.6 inches)
Ground clearance119mm (4.7 inches)
Unladen weight2565kg (5654.9 lbs)
Gross Vehicle Mass4490kg (9898.7 lbs)
Gross Combination Mass7000kg (15432.3 lbs)
Ford Transit 470E LWB JUMBO (DRW) Towing Capacity
Braked towing capacity3500kg (7716.2 lbs)
Unbraked towing capacity750kg (1653.5 lbs)
Ford Transit 470E LWB JUMBO (DRW) Warranty
Warranty length36 months
Warranty distance100,000km
Ford Transit 470E LWB JUMBO (DRW) Servicing
Service interval (km)15,000 km
Service interval (months)12 months
Ford Transit 470E LWB JUMBO (DRW) Options
Standard Features
  • 12 Volt Power Outlet
  • Dual Front Airbags Package
  • Anti-lock Braking
  • Air Conditioning
  • Adjustable Driver Seat - Manual
  • Alarm System/Remote Anti Theft
  • Antenna - Roof-mounted Bee-sting type
  • Adjustable Speed Limiter
  • Automatic Stop/Start
  • Adjustable Steering Wheel - Tilt & Telescopic
  • AUX/USB Input Socket
  • Brake Assist
  • Bottle Holders - Front Seats
  • Cruise Control
  • Cargo Tie Down Hooks/Rings
  • Central Locking Remote Control
  • Cloth Trim
  • Digital Audio Broadcast Radio
  • Dust and Pollen Filter
  • Door Pockets - Front Seat
  • Dynamic Stability Control
  • Daytime Running Lights
  • Electronic Brake Force Distribution
  • Exterior Mirrors - Heated
  • Emergency Stop Signal
  • Head Airbags
  • Headlights - Coming/Leaving Home Function
  • Hill Holder
  • Halogen Headlights
  • High Mounted Rear Stop Light
  • Illuminated - Entry/Exit with Delayed Fade
  • Engine Immobiliser
  • Intermittent Wipers - Variable
  • Luggage/Cargo Area Light(s)
  • Leather Steering Wheel
  • Mud Flaps - Front and Rear
  • Mobile Phone Connectivity
  • Map/Reading Lights - Front
  • Power Mirrors With Folding
  • Power Steering
  • Power Windows
  • Radio CD with 4 Speakers
  • Rear Wing Doors
  • Rollover Mitigation System
  • Side Airbags
  • Seatbelts - Lap/Sash for All Seats
  • Storage Compartment Under the Front Seats
  • Sliding Side Door
  • Steering Wheel-mounted Audio Controls
  • Spare Wheel - Space Saver/Temporary
  • Trip Computer
  • Traction Control System
  • Trailer Stability Control
  • Tinted Windows
Optional Features
  • City Pack - A$1,500
  • Metallic Paint - A$385
